new 720*1280 5.0 inch AE-7201280BOF-00 Touch LCD Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | AMPIRE |
| Model Number: | AE-7201280BOF-00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | AE-7201280BOF-00 | Diagonal Size: | 5.0" |
|---|---|---|---|
| Panel Type: | AM-OLED, OLED, Full Module | Resolution: | 720(RGB)×1280, WXGA 294PPI |
| Pixel Format: | RGBW Vertical Stripe | Active Area: | 62.1(W)×110.4(H) Mm |
| Used For: | Mobile Phone | Touch Screen: | On-Cell Touch |
Product Description
new 720*1280 5.0 inch AE-7201280BOF-00 Touch LCD Screen
AE-7201280BOF-00 LCD Panel Product details :
| Brand | AMPIRE |
| Model P/N | AE-7201280BOF-00 |
| Diagonal Size | 5.0" |
| Panel Type | AM-OLED, OLED, Full Module |
| Resolution | 720(RGB)×1280, WXGA 294PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 62.1(W)×110.4(H) mm |
| Bezel Opening | - |
| Outline Dim. | 65.7(H)×118.4(V)×0.7(D) mm |
| Treatment | - |
| Luminance | 310 cd/m² (Typ.) |
| Contrast Ratio | 10000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Max.)(Tr+Tf) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥200) |
| Operating Mode | - |
| Support Color | 16.7M 100%NTSC |
| Light Source | self |
| Weight | TBD |
| Designed For | Mobile Phone |
| Frame Rate | - |
| Touch Panel | On-Cell Touch |
| Interface Type | MIPI (4 data lanes), 31 pinsFPC |
| Power Supply | 3.3/3.3/4.6-3.5V (Typ.)(VCI/VDDI/ELVDD/ELVSS) |
| Environment | Operating Temperature: -20 ~ 60 °C; Storage Temperature: -30 ~ 70 °C |
| new 720*1280 5.0 inch AE-7201280BOF-00 Touch LCD Screen | |
AE-7201280BOF-00 LCD Display Features :
High Quality:
Highest quality touch LCD screen replacement parts.
Repair Utility:
Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.
Thorough Testing:
Each assembly is tested before shipping to ensure 100% functionality.
Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.
AE-7201280BOF-00 LCD Panel Shipping and Package :
AE-7201280BOF-00 LCD Display Shipping Policy :
Shipping Method:
If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.
Specified Logistics:
If you require a specific logistics company, please inform us in advance.
AE-7201280BOF-00 LCD Display Return Policy :
Product Status:
The product's condition (new or old) will be indicated in the product title.
Return and Exchange Conditions:
If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.
Return Procedure:
When returning the product, please provide a detailed explanation of the issues encountered.
Include actual photos showing the problems with the product.
AE-7201280BOF-00 LCD Panel FAQ :
Q: If I place order now,when will you ship the goods of AE-7201280BOF-00 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders of AE-7201280BOF-00 ?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of AE-7201280BOF-00 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of AE-7201280BOF-00 ?
A: we will give you tracking number then you can trace your order from website.
