New PD057VX1 640*480 5.7 inch 16.7M LCD Screen Display Module

All Category

Floor Standing Digital Signage

New PD057VX1 640*480 5.7 inch 16.7M LCD Screen Display Module

Brand Name:	E Ink
Model Number:	PD057VX1
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

PD057VX1

Diagonal Size:

Panel Type:

A-Si TFT-LCD, CELL, FOG

Resolution:

640(RGB)×480, VGA 141PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

115.2(W)×86.4(H) Mm

Designed For:

Industrial

Touchscreen:

Without

Supply Ability:

100000 Unit/Units per Month

Product Description

New PD057VX1 640*480 5.7 inch 16.7M LCD Screen Display Module

PD057VX1 LCD Panel Product details :

Brand	PVI
Model P/N	PD057VX1
Diagonal Size	5.7"
Panel Type	a-Si TFT-LCD, CELL, FOG
Resolution	640(RGB)×480, VGA 141PPI
Pixel Format	RGB Vertical Stripe
Active Area	115.2(W)×86.4(H) mm
Bezel Opening	-
Outline (mm)	124.3×96.5×1.83 (H×V×D)
Treatment	Antiglare, Hard coating (3H)
Luminance	0 cd/m²
Contrast Ratio	600 : 1 (Typ.) (TM)
Viewing Angle	50/70/75/75 (Typ.)(CR≥10)
Response	15/25 (Typ.)(Tr/Td) ms
Good View at	-
Work Mode	TN, Normally White, Transmissive
Glass Thickness	0.70+0.70 mm
Transmissivity	5.84% (Typ.)(with Polarizer)
Color Depth	16.7M
Backlight	No B/L
Mass	48.0±5.0g
Used for	Industrial
Refresh Rate	60Hz
Touchscreen	Without
Driver IC list	Built-in COG 2 source + 1 gate chips
Signal Type	Parallel RGB (1 ch, 8-bit) + SPI, FPC60 pins
Voltage Supply	3.3/3.3/8.0/17.6/-7.0V (Typ.)(VCC1/VCC2/VDDA/VGG/VEE)
Max. Ratings	Storage Temp.: -40 ~ 80 °C Operating Temp.: -30 ~ 70 °C
New PD057VX1 640*480 5.7 inch 16.7M LCD Screen Display Module

PD057VX1 LCD Panel Payment Instructions :

Accepted Payment Methods:

We prioritize the safety and convenience of our customers by accepting payments through Escrow, which allows you to pay securely online using your Credit Card.

Payment Timeline:

To ensure the timely processing and shipping of your order, please make your payment within 3 days of placing the order. Prompt payment is appreciated and helps us maintain efficient service. If you encounter any issues or delays with your payment, please don't hesitate to contact us immediately. We are here to assist you and resolve any problems to ensure a smooth transaction.

PD057VX1 LCD Panel Shipping and Package :

PD057VX1 LCD Panel Shipment Information :

Shipping Address:

We will ship your order to the address provided at the time of payment. Please ensure the address you entered is correct and up-to-date to avoid any delivery issues.

Estimated Delivery Time:

Typically, your order will arrive within 15-35 days. For orders shipped to Brazil, the estimated delivery time is 20-40 days. Some countries or regions may experience longer shipping times.

Delayed Shipments:

If your parcel has not arrived within the expected timeframe, please contact us first before taking any further action. We are here to assist you and will work to provide a satisfactory resolution.

Dispute Policy:

Please refrain from opening a dispute within the first 60 days after placing your order. If your order has not arrived after 60 days, you may contact us to request a refund or a resend of the product.

Customs Duty and Import Tax:

We are not responsible for any customs duties or import taxes that may be applicable in your country. Please check your local customs regulations for more information.

Important Instructions for Receiving and Handling Your PD057VX1 LCD Panel :

Inspecting the Package Upon Arrival:

When you receive the package, carefully inspect its condition.

If you notice any obvious damage, dents, or deformities, prepare to record a video as you open the package. This evidence is crucial for any potential claims.

Reporting Damaged Goods:

If you find that the LCD panel is damaged, immediately take detailed images and videos showing the damage.

Send these visuals to us to document the issue.

Our team will handle shipping-related damages but not those caused during installation. To secure your rights, provide the requested evidence and initiate a dispute for a refund if necessary.

Testing Before Installation:

After confirming the screen is undamaged, thoroughly test its functionality before proceeding with installation.

Do not attempt to install the screen yourself unless you are a professional. We recommend that installation be carried out by qualified technical personnel. We are not responsible for damages resulting from unprofessional installation.

Product Authenticity and Labels:

Each product from our store includes a unique anti-tear label.

Do not remove this label, as it verifies the product's authenticity and origin from our store.

Documenting Product Issues:

If you encounter any issues with the product, ensure that your video proof includes the labels as evidence.

Following these guidelines will help ensure a smooth process and protect your purchase rights. Thank you for your cooperation.

PD057VX1 LCD Panel FAQ :

Q: How to order if I don’t know the lcd panel number ?

A: You can offer 2-3 photos (back-side and front-side) for your lcd panel ,So that we can check the panel to you.

Q: What does "We may ship a 100% compatible part number for your screen" mean?

A: Because some original screens are not available in the market , So we send the compatible item to you .Don't worry , it is 100% compatible for your screen.

Q: What is the different between original lcd panel and compatible lcd display?

A: Function is the same , Of course the original lcd’s quality and lifetime better than that compatible lcd .

Q: Do you accept the PD057VX1 sample order?

A: Yes , sample order is welcome.
