7.1 inch TPA071-002V01 768*768 70Hz LVDS LCD Panel Screen Module

All Category

Floor Standing Digital Signage

7.1 inch TPA071-002V01 768*768 70Hz LVDS LCD Panel Screen Module

Brand Name:	BOE
Model Number:	TPA071-002V01
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

TPA071-002V01

Diagonal Size:

Panel Type:

A-Si TFT-LCD, CELL , FOG

Resolution:

768(RGB)×768 152PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

127.872(W)×127.872(H) Mm

Frame Rate:

Designed For:

Industrial \Square Display

Supply Ability:

100000 Unit/Units per Month

Product Description

7.1 inch TPA071-002V01 768*768 70Hz LVDS LCD Panel Screen Module

TPA071-002V01 LCD Panel Product details :

BOE LCD SCREEN
manufacturer	BOE
Model P/N	TPA071-002V01
Diagonal Size	7.1"
Panel Type	a-Si TFT-LCD, CELL , FOG
Resolution	768(RGB)×768 152PPI
Pixel Format	RGB Vertical Stripe
Active Area	127.872(W)×127.872(H) mm
Bezel Opening	-
Outline Dim.	139.8(H)×139.8(V) ×1.29(D) mm
Treatment	Antiglare, Hard coating (3H)
Luminance	0 cd/m²
Contrast Ratio	1100:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	30 (Max.)(Tr+Td)
Viewing Angle	85/85/85/85 (Min.)(CR≥10)
Operating Mode	ADS, Normally Black, Transmissive
Plate Thickness	0.50+0.50 mm
Transmittance	4.1% (Typ.)(with Polarizer)
Support Color	16.7M 70% NTSC
Light Source	No B/L
Weight	60.0g (Max.)
Designed For	Industrial Square Display
Frame Rate	70Hz
Touch Panel	Without
Interface Type	LVDS (1 ch, 8-bit) , 20 pins Connector
Power Supply	3.3V (Typ.)
Environment	Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -55 ~ 85 °C
7.1 inch TPA071-002V01 768*768 70Hz LVDS LCD Panel Screen Module

TPA071-002V01 LCD Display About Us :

Experience: We have over 15 years of experience in the industry, successfully serving more than 10,000 clients across 100 countries.

Product Range: We offer a wide variety of LCD panels and touch screens, acting as an agent for several renowned LCD brands including Kyocera, KOE, and Nanya. Our inventory frequently includes products from Sharp, NEC, Hitachi, AUO, Kyocera, and KOE, which can often be shipped within one day.

Quality and Pricing: We pride ourselves on providing high-quality products at competitive prices. Our goal is to meet your demands with the best products and services available.

TPA071-002V01 LCD Display Product Details :

Condition:

Before shipment, each unit undergoes multiple tests to ensure perfect functionality. We guarantee 100% quality for our products.

Order Guidance:

If you are uncertain whether this is the correct item for your needs, or if you require a larger quantity, please contact us before placing your order.

Product Authenticity:

The LCD screens are original and are thoroughly tested before being sent to you.

TPA071-002V01 LCD Display Friendly Reminder :

- Installation Guide:

- An installation guide is not included with the product. We are not responsible for any damage caused by the installation of this accessory. Please ensure you are knowledgeable about the installation process before purchasing.

- Professional Installation Recommended:

- Proper installation requires special skills and techniques. We recommend seeking the assistance of a qualified technician to carry out the repair.

- Disassembly Knowledge:

- Make sure you understand the disassembly procedure before making a purchase.

- Return Policy:

- Returns are only accepted if the item is in its original condition. We strongly recommend testing the item before installation.

TPA071-002V01 LCD Panel Shipping and Package :

7.1 inch TPA071-002V01 768*768 70Hz LVDS LCD Panel Screen Module 0

TPA071-002V01 LCD Panel FAQ :

Q: When will my order TPA071-002V01 ship?

A: The order are shipped within 1-2 working days after received the payment.

Q: Do you accept the sample order?

A: Yes , sample order is welcome.

Q: What does "We may ship a 100% compatible part number for your screen" mean?

A: Because some original screens are not available in the market , So we send the compatible item to you .Don't worry , it is 100% compatible for your screen.

Q: How long will I receive my goods of lcd TPA071-002V01 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
