1920*1080 QV116FHB-N80 11.6 inch 1000:1 LCD Panel Screen

All Category

Floor Standing Digital Signage

1920*1080 QV116FHB-N80 11.6 inch 1000:1 LCD Panel Screen

Brand Name:	BOE
Model Number:	QV116FHB-N80
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

QV116FHB-N80

Diagonal Size:

11.6"

Panel Type:

A-Si TFT-LCD, CELL, FOB

Resolution:

1920(RGB)×1080, FHD 190PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

256.32(W)×144.18(H) Mm

Touch Panel:

Without

Application:

Industrial

Supply Ability:

100000 Unit/Units per Month

Product Description

1920*1080 QV116FHB-N80 11.6 inch 1000:1 LCD Panel Screen

QV116FHB-N80 LCD Panel Product details :

Brand	BOE
Model P/N	QV116FHB-N80
Diagonal Size	11.6"
Panel Type	a-Si TFT-LCD, CELL, FOB
Resolution	1920(RGB)×1080, FHD 190PPI
Pixel Format	RGB Vertical Stripe
Active Area	256.32(W)×144.18(H) mm
Bezel Opening	-
Outline Dim.	260.32(H)×152.08(V)×1.06(D) mm
Treatment	Antiglare (Haze 25%), Hard coating (3H)
Luminance	0 cd/m²
Contrast Ratio	1000:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	30 (Typ.)(Tr+Td)
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Operating Mode	ADS, Normally Black, Transmissive
Plate Thickness	0.40+0.40 mm
Transmittance	-
Support Color	16.7M 72%NTSC
Light Source	No B/L, With LED Driver
Weight	TBD
Designed For	Industrial
Frame Rate	60Hz
Touch Panel	Without
D-IC Detail	COG Built-in 4 source chips
Interface Type	eDP (2 Lanes), 30 pinsConnector
Power Supply	3.3V (Typ.)
Environment	Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
