TM065JYHC05-00 6.5 inch 720*1600 LCD Screen Panel for Mobile Phone
Product Details:
| Place of Origin: | China |
| Brand Name: | TIANMA |
| Model Number: | TM065JYHC05-00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union, D/P |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TM065JYHC05-00 | Diagonal Size: | 6.5" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL, Full Cell | Resolution: | 720(RGB)×1600 267PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 68.256(W)×151.68(H) Mm |
| Designed For: | Mobile Phone | Light Source: | No B/L |
| Frame Rate: | 60Hz | Operating Mode: | ADS, Normally Black, Transmissive |
Product Description
TM065JYHC05-00 6.5 inch 720*1600 LCD Screen Panel for Mobile Phone
TM065JYHC05-00 LCD Panel Product details :
| Brand | TIANMA |
| Model P/N | TM065JYHC05-00 |
| Diagonal Size | 6.5" |
| Panel Type | a-Si TFT-LCD, CELL, Full Cell |
| Resolution | 720(RGB)×1600 267PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 68.256(W)×151.68(H) mm |
| Bezel Opening | - |
| Outline Dim. | 70.26(W)×155.98(H) mm |
| Luminance | 0 cd/m² |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Plate Thickness | - |
| Support Color | 16.7M 70% NTSC |
| Weight | - |
| Frame Rate | 60Hz |
| Treatment | - |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Response Time | 30 (Typ.)(Tr+Td) |
| Operating Mode | ADS, Normally Black, Transmissive |
| Transmittance | 4.3% (Typ.)(with APCF) |
| Light Source | No B/L |
| Designed For | Mobile Phone |
| Touch Panel | In-Cell Touch |
| D-IC Detail | COG Suggest NT36526, FT8009, HX83106-C, ILI9881X |
| Environment | Operating Temperature: -20 ~ 70 °C; Storage Temperature: -30 ~ 80 °C |
TM065JYHC05-00 LCD Panel Note :
Model Verification:
Please ensure that the model number you need is exactly the same as the model number you have ordered. We will ship the LCD panel based strictly on the model specified in your order. Ensuring the correct model number is crucial to avoid any compatibility issues.
Comprehensive Testing:
We conduct 100% testing on each LCD panel to ensure it meets our stringent quality standards. This thorough testing process guarantees that you receive a fully functional and reliable product. Our commitment to quality ensures that each panel is meticulously checked before it is shipped to you.
TM065JYHC05-00 LCD Panel Shipping and Package :
TM065JYHC05-00 LCD Panel Shipping Guidelines:
Address Confirmation:
It is crucial to verify that the shipping address provided in your order is accurate. We will ship the LCD panel to the address listed in the order. If you need the panel to be shipped to a different address, please email us the new address immediately after making the payment to avoid any shipping errors.
Shipment Timeline:
Your order will be processed and shipped within three business days after we have received your payment. Please note that business days do not include weekends or public holidays, so take this into account when estimating your delivery date.
TM065JYHC05-00 LCD Panel ESTIMATED DELIVERY TIME :
Standard Shipping:
The estimated delivery time for standard shipping is between 10 to 35 working days. This timeframe may vary depending on the destination and other factors such as customs processing and local postal services.
Expedited Shipping:
For a faster delivery option, expedited shipping is available with an estimated delivery time of 4 to 7 working days. This option is ideal if you need the LCD panel urgently and prefer a quicker shipping method.
TM065JYHC05-00 LCD Panel FAQ :
Q: How to order TM065JYHC05-00 ?
A: We accept T/T , PAYPAL , WESTERN UNION.
Q: When will ship my order of TM065JYHC05-00 ?
A: The order are shipped within 1-2 working days after received the payment.
Q: Can you test lcd panel TM065JYHC05-00 before shipping ?
A: Don't Worry , Our lcd TM065JYHC05-00 was tested ok before shipping
Q: Can you declared low value for my order lcd pane TM065JYHC05-00 ?
A: Yes we can , but you need to leave message to us before shipping .
Want to Know more details about this product
