Original 15.6 inch B156HAN09.0 HW1A 1920*1080 LCD Panel Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B156HAN09.0 HW1A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | B156HAN09.0 HW1A | Diagonal Size: | 15.6" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1920(RGB)×1080, FHD 141PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 344.16(W)×193.59(H) Mm |
| Used For: | Laptop | Form Style: | Slim (PCBA Flat, T≤3.2mm) |
| Luminance: | 400 Cd/m² (Typ.) | Contrast Ratio: | 1200:1 (Typ.) (TM) |
Product Description
Original 15.6 inch B156HAN09.0 HW1A 1920*1080 LCD Panel Screen
B156HAN09.0 HW1A LCD Panel Product details :
| Brand | AUO |
| Model P/N | B156HAN09.0 HW1A |
| Diagonal Size | 15.6" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 344.16(W)×193.59(H) mm |
| Bezel Opening | - |
| Outline Dim. | 349.16(W)×215.4(H)×2.6(D) mm |
| Treatment | Antiglare |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Support Color | 16.7M 100% sRGB |
| Light Source | WLED , 15K hours , With LED Driver |
| Form Style | Slim (PCBA Flat, T≤3.2mm) |
| Designed For | Laptop |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | eDP (2 Lanes) , eDP1.4 , 30 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
B156HAN09.0 HW1A LCD Panel Shipping and Package :
B156HAN09.0 HW1A LCD Panel FAQ :
Q: If I order B156HAN09.0 HW1A now,when will you ship the goods ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders for B156HAN09.0 HW1A ?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of B156HAN09.0 HW1A ?
A: Of course!If you make a large order, we will give you a discount.
Q:Can You declare my order of B156HAN09.0 HW1A at a very low value ?
A: Yes , we can . pls inform us before shipping .
Q: How can I trace my order of B156HAN09.0 HW1A ?
A: we will give you tracking number then you can trace your order from website.
Q: Can I pay my order of B156HAN09.0 HW1A via credit card ?
A: Yes!you can use your credit card through your Paypal account.
