M240HW01 VD CELL 24.0 inch 1920*1080 LCD Screen Display

Brand Name:	AUO
Model Number:	M240HW01 VD CELL
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Model Name:

M240HW01 VD CELL

Diagonal Size:

24.0"

Panel Type:

A-Si TFT-LCD, CELL , FOB

Resolution:

1920(RGB)×1080, FHD 91PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

531.36(W)×298.89(H) Mm

Display Colors:

16.7M

Light Source:

No B/L

Good View At:

6 O'clock

Designed For:

Desktop Monitor

Supply Ability:

100000 Unit/Units per Month

Product Description

M240HW01 VD CELL 24.0 inch 1920*1080 LCD Screen Display

M240HW01 VD CELL LCD Panel Product details :

Brand	AUO
Model P/N	M240HW01 VD CELL
Diagonal Size	24.0"
Panel Type	a-Si TFT-LCD, CELL , FOB
Resolution	1920(RGB)×1080, FHD 91PPI
Pixel Format	RGB Vertical Stripe
Active Area	531.36(W)×298.89(H) mm
Bezel Opening	-
Outline Dim.	546.86(W)×313.59(H)×1.9(D) mm
Treatment	Antiglare, Hard coating (3H)
Luminance	0 cd/m²
Contrast Ratio	1000:1 (Typ.) (TM)
View Direction	6 o'clock
Response Time	3.5/1.5 (Typ.)(Tr/Td) ms
Viewing Angle	85/85/80/80 (Typ.)(CR≥10)
Operating Mode	TN, Normally White, Transmissive
Glass Thickness	0.70+0.70 mm
Transmissivity	5.34% (Typ.)(with Polarizer)
Support Color	16.7M
Light Source	No B/L
Weight	-
Designed For	Desktop Monitor
Frame Rate	75Hz
Touch Panel	Without
Driver IC list	Built-in COF 6 source + 2 gate chips
Interface Type	LVDS (2 ch, 8-bit) , 30 pins Connector
Power Supply	5.0V (Typ.)
Environment	Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

M240HW01 VD CELL LCD Panel Notice:

Before placing your order for the M240HW01 VD CELL LCD panel, please carefully check and confirm the following details to ensure compatibility with your laptop:

Screen Size: Verify that the screen size matches your laptop's requirements.

Resolution: Ensure the resolution is compatible with your laptop.

Backlight Type: Confirm that the backlight type is suitable for your laptop model.

Interface Type and Location: Check that the interface type and its location are appropriate for your laptop's design.

If you are unsure about any of these specifications, please feel free to contact us for assistance. We are here to help you make an informed decision and ensure you select the correct LCD panel for your needs.

Customs Declaration:

If you would like us to declare a lower price on the package to reduce or avoid customs tax, please inform us at the time of your order. However, please note that by requesting this, you assume the risk of any potential issues that may arise with customs authorities.

M240HW01 VD CELL LCD Panel Shipping and Package :

M240HW01 VD CELL LCD Panel Packing:

We take great care to ensure that the M240HW01 VD CELL LCD panel is securely packed to prevent any damage during transit. The packing process involves multiple protective layers. First, the LCD panel is wrapped in a bubble bag, which provides a cushioned layer to absorb shocks and vibrations. This bubble bag acts as the first line of defense against impact.

Next, the bubble-wrapped LCD panel is placed inside a sturdy, strong box. This box is specifically chosen for its durability and ability to withstand external pressure. The combination of the bubble bag and the strong box ensures that the LCD panel remains intact and undamaged throughout its journey to you.

Additionally, we may include extra padding materials within the box to fill any voids and prevent the panel from shifting during transport. This meticulous packing process helps to ensure that the M240HW01 VD CELL LCD panel arrives at your doorstep in perfect working condition, ready for immediate use.

M240HW01 VD CELL LCD Panel Return Policy:

Inspection and Initial Reporting Period:

Upon receiving the M240HW01 VD CELL LCD panel, customers have a 7-day window to inspect and install the product. It is crucial to thoroughly check the panel for any damage or issues during this period. If the product is found to be damaged or dead-on-arrival (DOA), customers must report these issues within the 7-day timeframe to qualify for a return or exchange.

Exchange Policy for Defective Products:

If the M240HW01 VD CELL LCD panel exhibits any defects within 90 days of delivery, customers are eligible to exchange it for the exact same product. This policy ensures that you receive a fully functional panel without additional cost or hassle.

Different Product Exchange:

If a customer wishes to exchange the defective LCD panel for a different product, the process is treated as two separate transactions. First, the defective panel is returned, and a refund or credit is issued. Subsequently, the customer must place a new order for the desired product.

M240HW01 VD CELL LCD Panel FAQ :

Q: Can you tested the M240HW01 VD CELL before shipping ?

A: Of course , our lcd panel M240HW01 VD CELL was Strictly tested before shipping.

Q: How to order M240HW01 VD CELL ?

A: We accept T/T , Paypal , western union .

Q: What happen if the lcd panel M240HW01 VD CELL received can't work ?

A:M240HW01 VD CELL was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .

Q: Are you manufactory or trade company?

A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
