N116BGE-L42 11.6 inch 60HZ Laptop LCD Screen Display

Brand Name:	Chimei Innolux
Model Number:	N116BGE-L42
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

N116BGE-L42

Diagonal Size:

11.6"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1366(RGB)×768, WXGA 135PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

256.125(W)×144(H) Mm

Operating Mode:

TN, Normally White, Transmissive

Support Color:

262K 45% NTSC

Good View At:

6 O'clock

Designed For:

Laptop ，Netbook PC

Supply Ability:

100000 Unit/Units per Month

Product Description

N116BGE-L42 11.6 inch 60HZ Laptop LCD Screen Display

N116BGE-L42 LCD Panel Product details :

Brand	Chimei Innolux
Model P/N	N116BGE-L42
Diagonal Size	11.6"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1366(RGB)×768, WXGA 135PPI
Pixel Format	RGB Vertical Stripe
Active Area	256.125(W)×144(H) mm
Bezel Opening	259.125(W)×146.8(H) m
Outline Dim.	278(W)×168(H) ×3.4(D) mm
Treatment	Glare (Haze 0%), Hard coating (3H)
Luminance	200 cd/m² (Typ.)
Contrast Ratio	500:1 (Typ.) (TM)
View Direction	6 o'clock
Response Time	3/7 (Typ.)(Tr/Td)
Viewing Angle	45/45/20/45 (Typ.)(CR≥10)
Operating Mode	TN, Normally White, Transmissive
Support Color	262K 45% NTSC
Light Source	WLED , 12K hours , With LED Driver
Shape Style	Slim (PCBA Flat, T≤3.2mm)
Designed For	Laptop ,Netbook PC
Frame Rate	60Hz
Touch Panel	Without
Signal Interface	LVDS (1 ch, 6-bit) , 40 pins Connector
Input Voltage	3.3V (Typ.)
Environment	Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

N116BGE-L42 LCD Panel Notice:

Before placing your order for the N116BGE-L42 LCD panel, please carefully check and confirm the following details to ensure compatibility with your laptop:

Screen Size: Verify that the screen size matches your laptop's requirements.

Resolution: Ensure the resolution is compatible with your laptop.

Backlight Type: Confirm that the backlight type is suitable for your laptop model.

Interface Type and Location: Check that the interface type and its location are appropriate for your laptop's design.

If you are unsure about any of these specifications, please feel free to contact us for assistance. We are here to help you make an informed decision and ensure you select the correct LCD panel for your needs.

Customs Declaration:

If you would like us to declare a lower price on the package to reduce or avoid customs tax, please inform us at the time of your order. However, please note that by requesting this, you assume the risk of any potential issues that may arise with customs authorities.

N116BGE-L42 LCD Panel Shipping and Package :

N116BGE-L42 LCD Panel Packing:

We take great care to ensure that the N116BGE-L42 LCD panel is securely packed to prevent any damage during transit. The packing process involves multiple protective layers. First, the LCD panel is wrapped in a bubble bag, which provides a cushioned layer to absorb shocks and vibrations. This bubble bag acts as the first line of defense against impact.

Next, the bubble-wrapped LCD panel is placed inside a sturdy, strong box. This box is specifically chosen for its durability and ability to withstand external pressure. The combination of the bubble bag and the strong box ensures that the LCD panel remains intact and undamaged throughout its journey to you.

Additionally, we may include extra padding materials within the box to fill any voids and prevent the panel from shifting during transport. This meticulous packing process helps to ensure that the N116BGE-L42 LCD panel arrives at your doorstep in perfect working condition, ready for immediate use.

N116BGE-L42 LCD Panel Return Policy:

Inspection and Initial Reporting Period:

Upon receiving the N116BGE-L42 LCD panel, customers have a 7-day window to inspect and install the product. It is crucial to thoroughly check the panel for any damage or issues during this period. If the product is found to be damaged or dead-on-arrival (DOA), customers must report these issues within the 7-day timeframe to qualify for a return or exchange.

Exchange Policy for Defective Products:

If the N116BGE-L42 LCD panel exhibits any defects within 90 days of delivery, customers are eligible to exchange it for the exact same product. This policy ensures that you receive a fully functional panel without additional cost or hassle.

Different Product Exchange:

If a customer wishes to exchange the defective LCD panel for a different product, the process is treated as two separate transactions. First, the defective panel is returned, and a refund or credit is issued. Subsequently, the customer must place a new order for the desired product.

N116BGE-L42 LCD Panel FAQ :

Q: How long is the warranty of N116BGE-L42 ?

A: 90days warranty .

Q: Can you give me a discount if I need a large quantity of N116BGE-L42 ?

A: Of course!If you make a large order, we will give you a discount.

Q: How can I trace my order of N116BGE-L42 ?

A: we will give you tracking number then you can trace your order from website.

Q: Can I pay my goods N116BGE-L42 by credit card ?

A: Yes!you can use your credit card through your Paypal account.
