NEW SG1561B01-6 15.6 inch 1080p LCD Display Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | CSOT |
| Model Number: | SG1561B01-6 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | SG1561B01-6 | Diagonal Size: | 15.6" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL | Resolution: | 1920(RGB)×1080, FHD 141PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 344.16(W)×193.59(H) Mm |
| Outline Size: | 349.76(W)×202.09(H)×1.3(D) Mm | Surface: | Antiglare (Haze 25%), Hard Coating (3H) |
| Brightness: | 0 Cd/m² | Application: | Digital Signage |
Product Description
NEW SG1561B01-6 15.6 inch 1080p LCD Display Panel
SG1561B01-6 LCD Panel Product details :
| Brand | CSOT |
| Model P/N | SG1561B01-6 |
| Diagonal Size | 15.6" |
| Panel Type | a-Si TFT-LCD, CELL |
| Resolution | 1920(RGB)×1080, FHD 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 344.16(W)×193.59(H) mm |
| Bezel Opening | - |
| Outline Size | 349.76(W)×202.09(H)×1.3(D) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 0 cd/m² |
| Contrast Ratio | 3000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | HVA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Glass Depth | 0.50+0.50 mm |
| Transmissivity | 3.8% (Typ.) |
| Display Colors | 16.7M 72%NTSC |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Driver IC | COF Built-in 6 source chips |
| Panel Weight | - |
| Application | Digital Signage |
| Signal Interface | LVDS (2 ch, 8-bit), 40 pinsConnector |
| Input Voltage | 12V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
