C050SWAF-0 5.0 inch 720*1280 LCD Screen Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | IVO |
| Model Number: | C050SWAF-0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | C050SWAF-0 | Diagonal Size: | 5.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL , Full Cell, Q-CUT (Full Cell) | Resolution: | 720(RGB)×1280, WXGA 294PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 62.1(W)×110.4(H) Mm |
| Display Mode: | IPS, Normally Black | Support Color: | 16.7M 70%NTSC |
| View Direction: | Symmetry | Used For: | Mobile Phone |
Product Description
C050SWAF-0 5.0 inch 720*1280 LCD Screen Panel
C050SWAF-0 LCD Panel Product details :
| Brand | IVO |
| Model P/N | C050SWAF-0 |
| Diagonal Size | 5.0" |
| Panel Type | a-Si TFT-LCD, CELL , Full Cell, Q-CUT (Full Cell) |
| Resolution | 720(RGB)×1280, WXGA 294PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 62.1(W)×110.4(H) mm |
| Bezel Opening | - |
| Outline Size | 64.5(W)×117.69(H)×0.4(D) mm |
| Surface | Without Polarizer |
| Brightness | 0 cd/m² |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | IPS, Normally Black |
| Best View on | Symmetry |
| Response Time | 35 (Typ.)(Tr+Td) |
| Glass Depth | 0.20+0.20 mm |
| Transmissivity | 4.1% (Typ.)(with Polarizer) |
| Display Colors | 16.7M 70%NTSC |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Driver IC | COG Suggest OTM1284A, HX8394-D |
| Panel Weight | 7.54g (Typ.) |
| Application | Mobile Phone |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| 5.0 inch TFT LCD Panel C050SWAF-0 Original in Stock LCD Screen | |
