TL055VVXG31 5.5 inch 1080*1920 FHD LCD Screen Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | TIANMA |
| Model Number: | TL055VVXG31 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TL055VVXG31 | Diagonal Size: | 5.5" |
|---|---|---|---|
| Panel Type: | LTPS TFT-LCD, LCM | Resolution: | 1080(RGB)×1920, FHD 403PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 68.04(W)×120.96(H) Mm |
| Display Mode: | SFT, Normally Black, Transmissive | Support Color: | 16.7M 69%NTSC |
| View Direction: | Symmetry | Used For: | Mobile Phone |
Product Description
TL055VVXG31 5.5 inch 1080*1920 FHD LCD Screen Panel
TL055VVXG31 LCD Panel Product details :
| Brand | TIANMA |
| Model P/N | TL055VVXG31 |
| Diagonal Size | 5.5" |
| Panel Type | LTPS TFT-LCD, LCM |
| Resolution | 1080(RGB)×1920, FHD 403PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 68.04(W)×120.96(H) mm |
| Bezel Opening | - |
| Outline Size | 72.74(W)×131.91(H)×2.51(D) mm |
| Surface | - |
| Brightness | 400 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Display Mode | SFT, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 35 (Max.)(Tr+Td) |
| Display Colors | 16.7M 69%NTSC |
| Lamp Type | 7S2PWLED, Without Driver |
| Frequency | 60Hz |
| Touch Screen | - |
| Panel Weight | TBD |
| Application | Mobile Phone |
| Signal Interface | MIPI (4 data lanes), 34 pinsConnector |
| Input Voltage | 1.8/2.8V (Typ.)(VDD18/VDD28) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
TL055VVXG31 LCD Panel Shipping and Package :
Shipping Guarantee for TL055VVXG31 LCD Screen :
Traceable Shipping:
All shipments of the TL055VVXG31 LCD screen come with traceable package information. You can monitor the status and location of your package throughout the delivery process to ensure transparency and peace of mind.
Refund Policy:
In the unlikely event that you do not receive your package within 90 days of shipment, you are entitled to a full refund. Should this situation arise, please contact us promptly, and we will process your refund in full.
Warranty Details for TL055VVXG31 LCD Screen:
Warranty Period:
All TL055VVXG31 LCD panels are covered by a 60-day warranty from the date of receipt. This warranty ensures that the product you receive is free from defects and fully operational.
Reporting Issues:
In the event that the LCD panel is non-functional upon arrival, it is imperative that you notify us within 7 days of receipt. This prompt notification allows us to address the issue efficiently. Any claims reported beyond this 7-day window may not be eligible for warranty service, as we reserve the right to refuse such requests.
Problem Resolution:
Upon receiving your notification, our team will work closely with you to troubleshoot and resolve the issue. If the problem persists despite our best efforts, a Return Merchandise Authorization (RMA) can be issued. This process involves returning the faulty unit for repair or replacement.
TL055VVXG31 LCD Panel FAQ :
Q: Can you tested the TL055VVXG31 before shipping ?
A: Of course , our lcd panel TL055VVXG31 was Strictly tested before shipping.
Q: How to order TL055VVXG31 ?
A: We accept T/T , Paypal , western union .
Q: What happen if the lcd panel TL055VVXG31 received can't work ?
A:TL055VVXG31 was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
