F055A15-401 5.5 inch 720*1280 LCD Screen Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | F055A15-401 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | F055A15-401 | Diagonal Size: | 5.5" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL, Q-CUT (Full Cell) | Resolution: | 720(RGB)×1280, WXGA 268PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 68.04(W)×120.96(H) Mm |
| Display Mode: | AAS, Normally Black, Transmissive | Support Color: | 16.7M 68%NTSC |
| View Direction: | Symmetry | Used For: | Mobile Phone |
Product Description
F055A15-401 5.5 inch 720*1280 LCD Screen Panel
F055A15-401 LCD Panel Product details :
| Brand | Innolux |
| Model P/N | F055A15-401 |
| Diagonal Size | 5.5" |
| Panel Type | a-Si TFT-LCD, CELL, Q-CUT (Full Cell) |
| Resolution | 720(RGB)×1280, WXGA 268PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 68.04(W)×120.96(H) mm |
| Bezel Opening | - |
| Outline(mm) | 70.04 × 127.1× 0.8 (H×V×D) |
| Treatment | Without Polarizer |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Glass Thickness | 0.40+0.40 mm |
| Transmissivity | 3.55% (Typ.)(with Polarizer) |
| Color Depth | 16.7M 68%NTSC |
| Backlight | No B/L |
| Mass | - |
| Used for | Mobile Phone |
| Refresh Rate | - |
| Touchscreen | Without |
| Driver IC list | Suggest COG HX8394-F, NT35521S, OTM1284A, ILI9881C, JD9364 , JD9365 |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
1.Alipay is perferred and safety
2.Product being shipped outside of China will incur import duties taxes and charges etc.Those fees are not covered by either price or shipping charges of product,and are responsibility of recipient.
F055A15-401 LCD Panel Shipping and Package :
F055A15-401 LCD Screen Reminder :
Warranty Details for F055A15-401 LCD Screen:
Warranty Period:
All F055A15-401 LCD panels are covered by a 60-day warranty from the date of receipt. This warranty ensures that the product you receive is free from defects and fully operational.
Reporting Issues:
In the event that the LCD panel is non-functional upon arrival, it is imperative that you notify us within 7 days of receipt. This prompt notification allows us to address the issue efficiently. Any claims reported beyond this 7-day window may not be eligible for warranty service, as we reserve the right to refuse such requests.
Problem Resolution:
Upon receiving your notification, our team will work closely with you to troubleshoot and resolve the issue. If the problem persists despite our best efforts, a Return Merchandise Authorization (RMA) can be issued. This process involves returning the faulty unit for repair or replacement.
F055A15-401 LCD Panel FAQ :
Q: Can you give me a discount if I need a large quantity of F055A15-401 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of F055A15-401 ?
A: we will give you tracking number then you can trace your order from website.
Q: How to make payment of F055A15-401 ?
A: We accept T/T , Paypal , western union .
Q: Do you accept sample orders of F055A15-401 ?
A: Of course!sample order is welcome !
