Original TCG084XGLAAPNN-AN20-S 8.4 inch LCD Screen Display Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Kyocera |
| Model Number: | TCG084XGLAAPNN-AN20-S |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TCG084XGLAAPNN-AN20-S | Diagonal Size: | 8.4" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1024(RGB)×768, XGA 152PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 170.8(W)×128.1(H) Mm |
| Bezel Opening: | 174.9(W)×132.2(H) Mm | Outline Size: | 199.5(W)×149(H) ×11(D) Mm |
| Lamp Type: | WLED , 50K Hours , With LED Driver | Application: | Industrial /Outdoor High Brightness |
Product Description
Original TCG084XGLAAPNN-AN20-S 8.4 inch LCD Screen Display Panel
TCG084XGLAAPNN-AN20-S LCD Panel Product details :
| Brand | Kyocera |
| Model P/N | TCG084XGLAAPNN-AN20-S |
| Diagonal Size | 8.4" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×768, XGA 152PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 170.8(W)×128.1(H) mm |
| Bezel Opening | 174.9(W)×132.2(H) mm |
| Outline Size | 199.5(W)×149(H) ×11(D) mm |
| Surface | Antiglare |
| Brightness | 1000 cd/m² (Typ.) |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | AWV, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 12/11 (Typ.)(Tr/Td) |
| Display Colors | 262K/16.7M |
| Lamp Type | WLED , 50K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Shape Style | TBD |
| Application | Industrial /Outdoor High Brightness |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
TCG084XGLAAPNN-AN20-S LCD Display Features :
High Quality:
Highest quality touch LCD screen replacement parts.
Repair Utility:
Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.
Thorough Testing:
Each assembly is tested before shipping to ensure 100% functionality.
Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.
TCG084XGLAAPNN-AN20-S LCD Panel Shipping and Package :
TCG084XGLAAPNN-AN20-S LCD Display Shipping Policy :
Shipping Method:
If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.
Specified Logistics:
If you require a specific logistics company, please inform us in advance.
TCG084XGLAAPNN-AN20-S LCD Display Return Policy :
Product Status:
The product's condition (new or old) will be indicated in the product title.
Return and Exchange Conditions:
If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.
Return Procedure:
When returning the product, please provide a detailed explanation of the issues encountered.
Include actual photos showing the problems with the product.
TCG084XGLAAPNN-AN20-S LCD Panel FAQ :
Q: How long will I receive my goods TCG084XGLAAPNN-AN20-S ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: If I place order now,when will you ship the goods of TCG084XGLAAPNN-AN20-S ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders of TCG084XGLAAPNN-AN20-S ?
A: Of course!sample order is welcome !
Q: How long is the warranty ?
A: We offer 90days warranty .
Want to Know more details about this product
