• New LTM230HT04 1920*1080 23.0 inch 60Hz LCD Screen
New LTM230HT04 1920*1080 23.0 inch 60Hz LCD Screen

New LTM230HT04 1920*1080 23.0 inch 60Hz LCD Screen

Product Details:

Place of Origin: China
Brand Name: Samsung
Model Number: LTM230HT04

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 100000 Unit/Units per Month
Get Best Price Contact Now

Detail Information

Model Name: LTM230HT04 Diagonal Size: 23.0"
Panel Type: A-Si TFT-LCD, LCM Resolution: 1920(RGB)×1080, FHD 95PPI
Pixel Format: RGB Vertical Stripe Active Area: 509.76(W)×286.74(H) Mm
Used For: Desktop Monitor Frequency: 60Hz

Product Description

New LTM230HT04 1920*1080 23.0 inch 60Hz LCD Screen



LTM230HT04 LCD Panel Product details :



Brand Samsung
Model P/N LTM230HT04
Diagonal Size 23.0"
Panel Type a-Si TFT-LCD, LCM
Resolution 1920(RGB)×1080, FHD 95PPI
Pixel Format RGB Vertical Stripe
Active Area 509.76(W)×286.74(H) mm
Bezel Opening 513.8(W)×290.8(H) mm
Outline Dim. 534(W)×311.7(H)×11.9(D) mm
Luminance 250 cd/m² (Typ.)
View Direction -
Viewing Angle 80/80/80/80 (Typ.)(CR≥10)
Support Color 16.7M 70% NTSC
Weight 2.05Kgs (Max.)
Frame Rate 60Hz
Treatment Antiglare (Haze 25%), Hard coating (3H)
Contrast Ratio 1000:1 (Typ.) (TM)
Response Time 5 (Typ.)(Tr+Td)
Operating Mode TN, Normally White, Transmissive
Light Source WLED, 30K hours
Designed For Desktop Monitor
Touch Panel Without
Interface Type LVDS (2 ch, 8-bit)30 pins Connector
Power Supply 5.0V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C

LTM230HT04 LCD Display About Us :

Experience: We have over 15 years of experience in the industry, successfully serving more than 10,000 clients across 100 countries.

Product Range: We offer a wide variety of LCD panels and touch screens, acting as an agent for several renowned LCD brands including Kyocera, KOE, and Nanya. Our inventory frequently includes products from Sharp, NEC, Hitachi, AUO, Kyocera, and KOE, which can often be shipped within one day.

Quality and Pricing: We pride ourselves on providing high-quality products at competitive prices. Our goal is to meet your demands with the best products and services available.

LTM230HT04 LCD Display Product Details :

Condition:

Before shipment, each unit undergoes multiple tests to ensure perfect functionality. We guarantee 100% quality for our products.
Order Guidance:

If you are uncertain whether this is the correct item for your needs, or if you require a larger quantity, please contact us before placing your order.
Product Authenticity:

The LCD screens are original and are thoroughly tested before being sent to you.

LTM230HT04 LCD Display Friendly Reminder :

- Installation Guide:
- An installation guide is not included with the product. We are not responsible for any damage caused by the installation of this accessory. Please ensure you are knowledgeable about the installation process before purchasing.

- Professional Installation Recommended:
- Proper installation requires special skills and techniques. We recommend seeking the assistance of a qualified technician to carry out the repair.

- Disassembly Knowledge:
- Make sure you understand the disassembly procedure before making a purchase.

- Return Policy:
- Returns are only accepted if the item is in its original condition. We strongly recommend testing the item before installation.


LTM230HT04 LCD Panel Shipping and Package :

New LTM230HT04 1920*1080 23.0 inch 60Hz LCD Screen 0



LTM230HT04 LCD Panel FAQ :



Q: How can I trace my order of LTM230HT04 ?

A: we will give you tracking number then you can trace your order from website.



Q: How long is the warranty ?

A: We offer 90days warranty .



Q: Can I pay my order of LTM230HT04 via credit card ?

A: Yes!you can use your credit card through your Paypal account.



Q: Can You declare my order of LTM230HT04 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .
