Original 23.0 inch LTM230HT03 1920*1080 TFT-LCD Display Module

Brand Name:	Samsung
Model Number:	LTM230HT03
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LTM230HT03

Diagonal Size:

23.0"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1920(RGB)×1080, FHD 95PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

509.76(W)×286.74(H) Mm

Used For:

Desktop Monitor

Frequency:

Supply Ability:

100000 Unit/Units per Month

Product Description

Original 23.0 inch LTM230HT03 1920*1080 TFT-LCD Display Module

LTM230HT03 LCD Panel Product details :

Brand	Samsung
Model P/N	LTM230HT03
Diagonal Size	23.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080, FHD 95PPI
Pixel Format	RGB Vertical Stripe
Active Area	509.76(W)×286.74(H) mm
Bezel Opening	513.8(W)×290.8(H) mm
Outline Dim.	534(W)×311.7(H)×18.9(D) mm
Luminance	250 cd/m² (Typ.)
View Direction	-
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Support Color	16.7M 100% sRGB
Weight	3.00Kgs (Max.)
Frame Rate	60Hz
Treatment	Antiglare (Haze 25%), Hard coating (3H)
Contrast Ratio	1000:1 (Typ.) (TM)
Response Time	5 (Typ.)(Tr+Td)
Operating Mode	TN, Normally White, Transmissive
Light Source	CCFL [2 pcs] , 50K hours , W/O Driver
Designed For	Desktop Monitor
Touch Panel	Without
Interface Type	LVDS (2 ch, 8-bit)30 pins Connector
Power Supply	5.0V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C; Storage Temperature: -25 ~ 60 °C

LTM230HT03 LCD Display About Us :

Experience: We have over 15 years of experience in the industry, successfully serving more than 10,000 clients across 100 countries.

Product Range: We offer a wide variety of LCD panels and touch screens, acting as an agent for several renowned LCD brands including Kyocera, KOE, and Nanya. Our inventory frequently includes products from Sharp, NEC, Hitachi, AUO, Kyocera, and KOE, which can often be shipped within one day.

Quality and Pricing: We pride ourselves on providing high-quality products at competitive prices. Our goal is to meet your demands with the best products and services available.

LTM230HT03 LCD Display Product Details :

Condition:

Before shipment, each unit undergoes multiple tests to ensure perfect functionality. We guarantee 100% quality for our products.

Order Guidance:

If you are uncertain whether this is the correct item for your needs, or if you require a larger quantity, please contact us before placing your order.

Product Authenticity:

The LCD screens are original and are thoroughly tested before being sent to you.

LTM230HT03 LCD Display Friendly Reminder :

- Installation Guide:

- An installation guide is not included with the product. We are not responsible for any damage caused by the installation of this accessory. Please ensure you are knowledgeable about the installation process before purchasing.

- Professional Installation Recommended:

- Proper installation requires special skills and techniques. We recommend seeking the assistance of a qualified technician to carry out the repair.

- Disassembly Knowledge:

- Make sure you understand the disassembly procedure before making a purchase.

- Return Policy:

- Returns are only accepted if the item is in its original condition. We strongly recommend testing the item before installation.

LTM230HT03 LCD Panel Shipping and Package :

Original 23.0 inch LTM230HT03 1920*1080 TFT-LCD Display Module 0

LTM230HT03 LCD Panel FAQ :

Q: How do you ship my goods LTM230HT03 ?

A: We can shipping all over the world.via DHL,UPS,Fedex and EMS, the packaging is very safe and strong.

Q: How long is the warranty of LTM230HT03 ?

A: 90 days warranty .

Q: How can I trace my order of LTM230HT03 ?

A: we will give you tracking number then you can trace your order form website.

Q: Can you give me a discount if I need a large quantity of LTM230HT03 ?

A: Of course!If you make a large order, we will give you a discount.
