LQ190N1LX01 19.0 inch 1680*1050 LCD Display Screen FOR Industrial

Brand Name:	Sharp
Model Number:	LQ190N1LX01
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LQ190N1LX01

Diagonal Size:

19.0"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1680(RGB)×1050, WSXGA+ 104PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

409.5(W)×255.94(H) Mm

Designed For:

Industrial、Medical Imaging

Frame Rate:

Supply Ability:

100000 Unit/Units per Month

Product Description

LQ190N1LX01 19.0 inch 1680*1050 LCD Display Screen FOR Industrial

LQ190N1LX01 LCD Panel Product details :

Brand	Sharp
Model P/N	LQ190N1LX01
Diagonal Size	19.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1680(RGB)×1050, WSXGA+ 104PPI
Pixel Format	RGB Vertical Stripe
Active Area	409.5(W)×255.94(H) mm
Bezel Opening	413.9(W)×260.3(H) mm
Outline Dim.	444(H)×283.3(V)×16(D) mm
Treatment	Antiglare (Haze 3%), Hard coating (3H)
Luminance	300 cd/m² (Typ.)
Contrast Ratio	900:1 (Typ.) (TM)
View Direction	-
Response Time	35 (Typ.)(Tr+Td)
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Operating Mode	TN, Normally White, Transmissive
Support Color	16.7M 71%NTSC
Light Source	WLED, 50K hours, With LED Driver
Weight	1.6Kgs (Typ.)
Designed For	Industrial,Medical Imaging
Frame Rate	60Hz
Touch Panel	Without
Interface Type	LVDS (2 ch, 8-bit), 30 pinsConnector
Power Supply	12.0V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C
LQ190N1LX01 19.0 inch 1680*1050 LCD Display Screen FOR Industrial

LQ190N1LX01 LCD Display About Us :

Experience: We have over 15 years of experience in the industry, successfully serving more than 10,000 clients across 100 countries.

Product Range: We offer a wide variety of LCD panels and touch screens, acting as an agent for several renowned LCD brands including Kyocera, KOE, and Nanya. Our inventory frequently includes products from Sharp, NEC, Hitachi, AUO, Kyocera, and KOE, which can often be shipped within one day.

Quality and Pricing: We pride ourselves on providing high-quality products at competitive prices. Our goal is to meet your demands with the best products and services available.

LQ190N1LX01 LCD Display Product Details :

Condition:

Before shipment, each unit undergoes multiple tests to ensure perfect functionality. We guarantee 100% quality for our products.

Order Guidance:

If you are uncertain whether this is the correct item for your needs, or if you require a larger quantity, please contact us before placing your order.

Product Authenticity:

The LCD screens are original and are thoroughly tested before being sent to you.

LQ190N1LX01 LCD Display Friendly Reminder :

- Installation Guide:

- An installation guide is not included with the product. We are not responsible for any damage caused by the installation of this accessory. Please ensure you are knowledgeable about the installation process before purchasing.

- Professional Installation Recommended:

- Proper installation requires special skills and techniques. We recommend seeking the assistance of a qualified technician to carry out the repair.

- Disassembly Knowledge:

- Make sure you understand the disassembly procedure before making a purchase.

- Return Policy:

- Returns are only accepted if the item is in its original condition. We strongly recommend testing the item before installation.

LQ190N1LX01 LCD Panel Shipping and Package :

LQ190N1LX01 19.0 inch 1680*1050 LCD Display Screen FOR Industrial 0

LQ190N1LX01 LCD Panel FAQ :

Q: How can I trace my order of LQ190N1LX01 ?

A: we will give you tracking number then you can trace your order from website.

Q: How to make payment of LQ190N1LX01 ?

A: We accept T/T , Paypal , western union .

Q: Do you accept sample orders of LQ190N1LX01 ?

A: Of course!sample order is welcome !

Q: Can you give me a discount if I need a large quantity of LQ190N1LX01 ?

A: Of course!If you make a large order, we will give you a discount.
