LD550DUN-TGA3 55.0 inch 1920*1080 LCD Display Screen for Video Wall

Brand Name:	LG
Model Number:	LD550DUN-TGA3
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LD550DUN-TGA3

Diagonal Size:

55.0"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1920(RGB)×1080, FHD 40PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

1209.6(W)×680.4(H) Mm

Operating Mode:

S-IPS, Normally Black, Transmissive

Light Source:

WLED, 60K Hours, With LED Driver

View Direction:

Symmetry

Application:

Video Wall

Supply Ability:

100000 Unit/Units per Month

Product Description

LD550DUN-TGA3 55.0 inch 1920*1080 LCD Display Screen for Video Wall

LD550DUN-TGA3 LCD Panel Product details :

Brand	LG Display
Model P/N	LD550DUN-TGA3
Diagonal Size	55"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080, FHD 40PPI
Pixel Format	RGB Vertical Stripe
Active Area	1209.6(W)×680.4(H) mm
Bezel Opening	1209.9(W)×680.7(H) mm
Outline(mm)	1213.4 × 684.2× 51.3 (H×V×D)
Treatment	Antiglare (Haze 44%), Hard coating (3H)
Luminance	700 cd/m² (Typ.)
Contrast Ratio	1200 : 1 (Typ.) (TM)
Viewing Angle	89/89/89/89 (Min.)(CR≥10)
Response	12 (Typ.)(G to G) ms
Good View at	Symmetry
Work Mode	S-IPS, Normally Black, Transmissive
Color Depth	1.06B 99%sRGB
Backlight	WLED, 60K hours, With LED Driver
Splicing Seam	3.8 mm (active to active seam)
Used for	Video Wall
Refresh Rate	60Hz
Touchscreen	Without
Signal Type	LVDS (2 ch, 10-bit), 51 pinsConnector
Voltage Supply	12.0V (Typ.)
Max. Ratings	Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
LD550DUN-TGA3 55.0 inch 1920*1080 LCD Display Screen for Video Wall

LD550DUN-TGA3 Pre-Order Check:

Before proceeding with your order, kindly verify if your machine model is compatible with this specific LCD screen. If you're uncertain, please reach out to us, and we'll promptly assist you.

Note:

Some of the screen backplates may not be entirely new, potentially showing signs of dirt or adhesive residue. Please take note of this!

LD550DUN-TGA3 LCD Panel Shipping and Package :

LD550DUN-TGA3 Shipping Information:

Please ensure that the model you've ordered matches exactly with the model you require. We will ship according to the model specified in your order.

Verify that the shipping address provided is accurate. Shipments will be sent to the address listed on the order. If you need delivery to a different address, please email us immediately after making the payment.

Shipments will be processed within 3 business days of receiving payment.

Each LCD panel undergoes rigorous testing before shipping, ensuring quality. Additionally, we take utmost care in packaging to ensure safe delivery.

LCD screens will be shipped using EMS/DHL/UPS based on location or customer preference.

Attention to Russian Customers:

For shipments to Russia, we can only use EMS. Please note that EMS delivery typically takes longer to arrive. We appreciate your patience during this time.

LD550DUN-TGA3 About the Goods:

Upon receiving your item, please confirm receipt. In the event that the item is damaged, kindly contact us immediately. Send us a photo of the damage so we can assess the situation and offer you the best solution.

While we guarantee timely delivery, please note that we do not have control over the express delivery time. Our dedicated sales staff will dispatch the Air Waybill (AWB) for your delivered goods on the following business day. You can track the AWB on the designated website provided to you. Alternatively, you can inquire about the AWB by contacting your local branch of the courier company handling the shipment.

LD550DUN-TGA3 LCD Panel FAQ :

Q: How long is the warranty ?

A: We offer 90days warranty .

Q: If I place order now,when will you ship the goods of LD550DUN-TGA3 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can I pay my order of LD550DUN-TGA3 via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: How long will I receive my goods LD550DUN-TGA3 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
