LQ185M3LW01 18.5 inch LCD Module Screen Panel Display

Brand Name:	Sharp
Model Number:	LQ185M3LW01
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LQ185M3LW01

Diagonal Size:

18.5"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1920(RGB)×1080, FHD 119PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

408.96(W)×230.04(H) Mm

Designed For:

Industrial

Frame Rate:

Supply Ability:

100000 Unit/Units per Month

Product Description

LQ185M3LW01 18.5 inch LCD Module Screen Panel Display

LQ185M3LW01 LCD Panel Product details :

Brand	Sharp
Model P/N	LQ185M3LW01
Diagonal Size	18.5"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080, FHD 119PPI
Pixel Format	RGB Vertical Stripe
Active Area	408.96(W)×230.04(H) mm
Bezel Opening	413.4(W)×234.44(H) mm
Outline(mm)	430.4 × 254.6× 11.3 (H×V×D)
Treatment	Antiglare, Hard coating
Luminance	400 cd/m² (Typ.)
Contrast Ratio	1500 : 1 (Typ.) (TM)
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Response	35 (Typ.)(Tr+Td) ms
Good View at	Symmetry
Work Mode	ASV, Normally Black, Transmissive
Color Depth	16.7M 69%NTSC
Backlight	WLED, 50K hours, With LED Driver
Mass	1.12Kgs (Typ.)
Used for	Industrial
Refresh Rate	60Hz
Touchscreen	Without
Signal Type	LVDS (2 ch, 8-bit), 30 pinsConnector
Voltage Supply	5.0V (Typ.)
Max. Ratings	Storage Temp.: -25 ~ 70 °C Operating Temp.: -20 ~ 70 °C
LQ185M3LW01 18.5 inch LCD Module Screen Panel Display

LQ185M3LW01 LCD Display About Us :

Experience: We have over 15 years of experience in the industry, successfully serving more than 10,000 clients across 100 countries.

Product Range: We offer a wide variety of LCD panels and touch screens, acting as an agent for several renowned LCD brands including Kyocera, KOE, and Nanya. Our inventory frequently includes products from Sharp, NEC, Hitachi, AUO, Kyocera, and KOE, which can often be shipped within one day.

Quality and Pricing: We pride ourselves on providing high-quality products at competitive prices. Our goal is to meet your demands with the best products and services available.

LQ185M3LW01 LCD Display Product Details :

Condition:

Before shipment, each unit undergoes multiple tests to ensure perfect functionality. We guarantee 100% quality for our products.

Order Guidance:

If you are uncertain whether this is the correct item for your needs, or if you require a larger quantity, please contact us before placing your order.

Product Authenticity:

The LCD screens are original and are thoroughly tested before being sent to you.

LQ185M3LW01 LCD Display Friendly Reminder :

- Installation Guide:

- An installation guide is not included with the product. We are not responsible for any damage caused by the installation of this accessory. Please ensure you are knowledgeable about the installation process before purchasing.

- Professional Installation Recommended:

- Proper installation requires special skills and techniques. We recommend seeking the assistance of a qualified technician to carry out the repair.

- Disassembly Knowledge:

- Make sure you understand the disassembly procedure before making a purchase.

- Return Policy:

- Returns are only accepted if the item is in its original condition. We strongly recommend testing the item before installation.

LQ185M3LW01 LCD Panel Shipping and Package :

LQ185M3LW01 18.5 inch LCD Module Screen Panel Display 0

LQ185M3LW01 LCD Panel FAQ :

Q: Do you accept the sample order?

A: Yes , sample order is welcome.

Q: How to order if I don't know the lcd panel number ?

A: You can offer 2-3 photos (back-side and front-side) for your lcd panel ,So that we can check the panel to you.

Q: Can you declared low value for my order when shipping?

A: Yes, We can do it for you if you need.

Q: When would you ship,IF I order LQ185M3LW01 now?

A: The order are shipped within 1-2 working days after received the payment.
