LD083WU1-SPA3 8.3 inch 1200*1920 LCD Display with touch screen
Product Details:
| Place of Origin: | China |
| Brand Name: | LG |
| Model Number: | LD083WU1-SPA3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LD083WU1-SPA3 | Diagonal Size: | 8.3" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, Assembly | Resolution: | 1200(RGB)×1920, WUXGA 273PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 111.31(W)×178.1(H) Mm |
| Support Color: | 16.7M 60%NTSC | Light Source: | WLED, 15K Hours, Without Driver |
| View Direction: | Symmetry | Designed For: | Pad & Tablet |
Product Description
LD083WU1-SPA3 8.3 inch 1200*1920 LCD Display with touch screen
LD083WU1-SPA3 LCD Panel Product details :
| Brand | LG Display |
| Model P/N | LD083WU1-SPA3 |
| Diagonal Size | 8.3" |
| Panel Type | a-Si TFT-LCD, Assembly |
| Resolution | 1200(RGB)×1920, WUXGA 273PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 111.31(W)×178.1(H) mm |
| Bezel Opening | - |
| Outline Size | 128(W)×220.3(H)×7.86(D) mm |
| Surface | Anti Fingerprint, Hard coating (8H) |
| Brightness | 370 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Tf) |
| Display Colors | 16.7M 60%NTSC |
| Lamp Type | WLED, 15K hours, Without Driver |
| Frequency | 60Hz |
| Touch Screen | PCAP, I²C |
| Panel Weight | 53.6g (Max.) |
| Application | Pad & Tablet |
| Signal Interface | eDP (2 Lanes) , HBR1 (2.7G/lane) , 34 pinsConnector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LD083WU1-SPA3 8.3 inch 1200*1920 LCD Display with touch screen | |
LD083WU1-SPA3 LCD Panel Special Instructions for International Buyers :
For Buyers in Brazil
If you are shipping the goods to Brazil using DHL, FEDEX, or EMS, please provide us with your CNPJ or CPF number. This information is required for customs clearance.
For Buyers in Russia
For shipments to Russia, we can only ship via EMS or ePacket. Please provide the full name of the receiver to ensure accurate delivery.
Duty and Custom Fees
Import duties or custom fees are the responsibility of the buyer and are determined by the buyer's country. If you need us to declare a lower value for customs purposes, please inform us promptly.
For Buyers in Remote Areas
If you are located in a remote area and choose to ship via FEDEX or DHL, an additional fee of USD 35.00 will be applied. We appreciate your understanding regarding this extra cost.
LD083WU1-SPA3 LCD Panel Shipping and Package :
LD083WU1-SPA3 LCD Panel Shipment Guidelines :
1. Confirm the Model
Before completing your purchase, please double-check that the model you need is exactly the LD083WU1-SPA3 We will ship the product based on the model specified in your order. If there are any discrepancies or you need to make changes, please contact us immediately.
2. Verify the Shipping Address
Ensure that the shipping address provided in your order is accurate and complete. We will deliver your order to the address listed in the order details. If you need the shipment to be sent to a different address, please email us the correct address as soon as you have completed your payment. Prompt notification will help us to update the shipping details accordingly.
3. Shipping Timeline
We strive to process and ship all orders promptly. Shipments will be dispatched within 3 business days after we have received your payment. This timeline ensures that we have sufficient time to prepare your order for shipping while maintaining our quality standards.
4. Quality Control and Packaging
Each LCD panel undergoes rigorous testing before it is shipped. This thorough testing process ensures that the panel meets our high standards of quality and functionality. Additionally, we take great care in packaging the LCD panels to prevent any damage during transit. Our secure and robust packaging methods aim to deliver the product to you in perfect condition.
LD083WU1-SPA3 LCD Panel Warranty Information :
Warranty Period
All LD083WU1-SPA3 LCD panels come with a 60-day warranty from the date of delivery. This warranty covers any defects or issues that may arise with the product during this period.
Reporting Issues
If you discover that the LCD panel is not working correctly upon receipt, please notify us within 7 days. This initial period is crucial for us to address any immediate concerns and provide timely assistance. Notifications received after 7 days may not be eligible for warranty claims, as we reserve the right to refuse any requests made beyond this period.
Assistance and Problem Resolution
Once you inform us of an issue within the specified 7-day window, our team will work with you to resolve the problem as quickly as possible. We aim to provide effective solutions and support to ensure your satisfaction.
Return Merchandise Authorization (RMA)
If the issue cannot be resolved through our support and communication, we will accept a Return Merchandise Authorization (RMA) request. This process allows you to return the defective LCD panel for repair, replacement, or refund as deemed appropriate.
LD083WU1-SPA3 LCD Panel FAQ :
Q: Can I pay my order of LD083WU1-SPA3 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of LD083WU1-SPA3 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Do you accept sample orders of LD083WU1-SPA3 ?
A: Of course!sample order is welcome !
Q: How can I trace my order of LD083WU1-SPA3 ?
A: we will give you tracking number then you can trace your order from website.
