DV320WHD-NT0 32.0 inch 1366*768 LCD Screen FOR Transparent Display
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | DV320WHD-NT0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | DV320WHD-NT0 | Diagonal Size: | 32.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1366(RGB)×768, WXGA 49PPI |
| Pixel Format: | RGB Vertical Stripe | Luminance: | 697.685(W)×392.256(H) Mm |
| Used For: | Digital Signage、Transparent Display | Touch Panel: | Without |
Product Description
DV320WHD-NT0 32.0 inch 1366*768 LCD Screen FOR Transparent Display
DV320WHD-NT0 LCD Panel Product details :
| Brand | BOE |
| Model P/N | DV320WHD-NT0 |
| Diagonal Size | 32.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1366(RGB)×768, WXGA 49PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 697.685(W)×392.256(H) mm |
| Bezel Opening | 700.7(W)×395.3(H) mm |
| Outline Size | 740.7(W)×461.3(H)×9.6(D) mm |
| Treatment | - |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 8 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 72%NTSC |
| Backlight | No B/L |
| Mass | 1.69Kgs (Typ.) |
| Used for | Digital Signage,Transparent Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 8-bit), 30 pinsConnector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| DV320WHD-NT0 32.0 inch 1366*768 LCD Screen FOR Transparent Display | |
