DV270FHM-R01 27.0 inch 1920*1080 1500 cd/m2 LCD Screen For Industria
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | DV270FHM-R01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | DV270FHM-R01 | Diagonal Size: | 27.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1920(RGB)×1080, FHD 81PPI |
| Pixel Format: | RGB Vertical Stripe | Luminance: | 597.888(W)×336.312(H) Mm |
| Used For: | Industrial、Digital Signage、Outdoor High Brightness | Touch Panel: | Without |
Product Description
DV270FHM-R01 27.0 inch 1920*1080 1500 cd/m2 LCD Screen For Industria
DV270FHM-R01 LCD Panel Product details :
| Brand | BOE |
| Model P/N | DV270FHM-R01 |
| Diagonal Size | 27.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 81PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 597.888(W)×336.312(H) mm |
| Bezel Opening | 602(W)×339.8(H) mm |
| Outline (mm) | 626×363.8×15 (H×V×D) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 1500 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | TBD |
| Response | 20 (Max.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 100%sRGB |
| Backlight | WLED, 50K hours, No Driver |
| Mass | 3.40Kgs (Typ.) |
| Used for | Industrial,Digital Signage,Outdoor High Brightness |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit), Connector30 pins |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 80 °C |
| DV270FHM-R01 27.0 inch 1920*1080 1500 cd/m2 LCD Screen For Industria | |
DV270FHM-R01 LCD Panel Shipping and Package :
DV270FHM-R01 LCD Panel FAQ :
Q: Can you declared low value for my order when shipping?
A: Yes, We can do it for you if you need.
Q: How to do if I can't find the screen that I require in your listings?
A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .
Q: Why big order delivery time are long?
A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
