DV215FHM-R10 21.5 inch 1920*1080 1500 cd/m2 LCD Display Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | DV215FHM-R10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | DV215FHM-R10 | Diagonal Size: | 21.5" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1920(RGB)×1080, FHD 102PPI |
| Pixel Format: | RGB Vertical Stripe | Luminance: | 478.656(W)×260.28(H) Mm |
| Used For: | Industrial、Digital Signage、Outdoor High Brightness | Touch Panel: | Without |
Product Description
DV215FHM-R10 21.5 inch 1920*1080 1500 cd/m2 LCD Display Screen
DV215FHM-R10 LCD Panel Product details :
| Brand | BOE |
| Model P/N | DV215FHM-R10 |
| Diagonal Size | 21.5" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 102PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 478.656(W)×260.28(H) mm |
| Bezel Opening | 481.1(W)×262.7(H) mm |
| Outline Size | 499(W)×286.2(H)×15.2(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 1500 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 14 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 72%NTSC |
| Backlight | 17S4PWLED, 50K hours, No Driver |
| Mass | 2.00Kgs (Typ.) |
| Used for | Industrial,Digital Signage,Outdoor High Brightness |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit), 30 pinsConnector |
| Voltage Supply | 5.5V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 85 °C |
| DV215FHM-R10 21.5 inch 1920*1080 1500 cd/m2 LCD Display Screen | |
