15.0 inch 720*1920 COG-VLUK7057-01 950 cd/m2 LCD Touch Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | COG-VLUK7057-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | COG-VLUK7057-01 | Diagonal Size: | 15.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 720(RGB)×1920 137PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 133.38(W)×355.68(H) Mm |
| Used For: | Outdoor High Brightness、Automotive Display | Frequency: | 60Hz |
Product Description
15.0 inch 720*1920 COG-VLUK7057-01 950 cd/m2 LCD Touch Screen
COG-VLUK7057-01 LCD Panel Product details :
| Brand | BOE |
| Model P/N | COG-VLUK7057-01 |
| Diagonal Size | 15.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 720(RGB)×1920 137PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 133.38(W)×355.68(H) mm |
| Bezel Opening | - |
| Outline(mm) | 168.41 × 391.22× 14.16 (H×V×D) |
| Treatment | Anti Fingerprint, Hard coating (3H), Antireflection |
| Luminance | 950 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 30 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 70%NTSC |
| Backlight | 11S4PWLED, No Driver |
| Mass | 228g (Max.) |
| Used for | Outdoor High Brightness,Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | On-Cell Touch |
| Signal Type | LVDS (2 ch, 8-bit), 60 pinsConnector |
| Voltage Supply | 3.3/6.3/-6.3/16.8/-11V (Typ.)(DVDD/VSP/VSN/VGH/VGL) |
| Max. Ratings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C |
| 15.0 inch 720*1920 COG-VLUK7057-01 950 cd/m2 LCD Touch Screen | |
