LCD Touch Panel Display

COG-VLSZT101-01 15.6 inch 1920*1080 LCD Screen FOR Outdoor High Brightness

All Category

Floor Standing Digital Signage

COG-VLSZT101-01 15.6 inch 1920*1080 LCD Screen FOR Outdoor High Brightness

Brand Name:	BOE
Model Number:	COG-VLSZT101-01
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

COG-VLSZT101-01

Diagonal Size:

15.6"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1920(RGB)×1080, FHD 141PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

345.6(W)×194.4(H) Mm

Used For:

Outdoor High Brightness、Automotive Display

Frequency:

Supply Ability:

100000 Unit/Units per Month

Product Description

COG-VLSZT101-01 15.6 inch 1920*1080 LCD Screen FOR Outdoor High Brightness

COG-VLSZT101-01 LCD Panel Product details :

Brand	BOE
Model P/N	COG-VLSZT101-01
Diagonal Size	15.6"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080, FHD 141PPI
Pixel Format	RGB Vertical Stripe
Active Area	345.6(W)×194.4(H) mm
Bezel Opening	348.2(W)×197.4(H) mm
Outline Dim.	358.6(W)×214.3(H) mm
Luminance	850 cd/m² (Typ.)
View Direction	Symmetry
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Support Color	16.7M 75% NTSC
Weight	-
Frame Rate	60Hz
Treatment	Hard coating, Reflection 6.0% (Max.)
Contrast Ratio	1200:1 (Typ.) (TM)
Response Time	25 (Max.)(Tr+Td)
Operating Mode	ADS, Normally Black, Transmissive
Light Source	WLED [8S6P] , 30K hours , W/O Driver
Designed For	Outdoor High Brightness,Automotive Display
Touch Panel	On-Cell Touch, I²C
Interface Type	LVDS (2 ch, 8-bit)60 pins Connector
Power Supply	3.3V (Typ.)
Environment	Operating Temperature: -30 ~ 85 °C; Storage Temperature: -40 ~ 90 °C; Vibration Level: 3.0G (29.4 m/s²)
COG-VLSZT101-01 15.6 inch 1920*1080 LCD Screen FOR Outdoor High Brightness

COG-VLSZT101-01 LCD Display About Us :

Experience: We have over 15 years of experience in the industry, successfully serving more than 10,000 clients across 100 countries.

Product Range: We offer a wide variety of LCD panels and touch screens, acting as an agent for several renowned LCD brands including Kyocera, KOE, and Nanya. Our inventory frequently includes products from Sharp, NEC, Hitachi, AUO, Kyocera, and KOE, which can often be shipped within one day.

Quality and Pricing: We pride ourselves on providing high-quality products at competitive prices. Our goal is to meet your demands with the best products and services available.

COG-VLSZT101-01 LCD Display Product Details :

Condition:

Before shipment, each unit undergoes multiple tests to ensure perfect functionality. We guarantee 100% quality for our products.

Order Guidance:

If you are uncertain whether this is the correct item for your needs, or if you require a larger quantity, please contact us before placing your order.

Product Authenticity:

The LCD screens are original and are thoroughly tested before being sent to you.

COG-VLSZT101-01 LCD Display Friendly Reminder :

- Installation Guide:

- An installation guide is not included with the product. We are not responsible for any damage caused by the installation of this accessory. Please ensure you are knowledgeable about the installation process before purchasing.

- Professional Installation Recommended:

- Proper installation requires special skills and techniques. We recommend seeking the assistance of a qualified technician to carry out the repair.

- Disassembly Knowledge:

- Make sure you understand the disassembly procedure before making a purchase.

- Return Policy:

- Returns are only accepted if the item is in its original condition. We strongly recommend testing the item before installation.

COG-VLSZT101-01 LCD Panel Shipping and Package :

COG-VLSZT101-01 15.6 inch 1920*1080 LCD Screen FOR Outdoor High Brightness 0

COG-VLSZT101-01 LCD Panel FAQ :

Q: Do you accept sample orders of COG-VLSZT101-01?

A: Of course!sample order is welcome !

Q: Can I pay my order of COG-VLSZT101-01 via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: Can You declare my order of COG-VLSZT101-01 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: Can you give me a discount if I need a large quantity of COG-VLSZT101-01?

A: Of course!If you make a large order, we will give you a discount.
