LCD Screen Display Panel

23.6 inch 1920*1080 LCD Screen Display V236HGE-L23 For Desktop Monitor

All Category

Floor Standing Digital Signage

23.6 inch 1920*1080 LCD Screen Display V236HGE-L23 For Desktop Monitor

Brand Name:	Chimei Innolux
Model Number:	V236HGE-L23
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

V236HGE-L23

Diagonal Size:

23.6"

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1920(RGB)×1080, FHD 93PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

521.28(W)×293.22(H) Mm

Contrast Ratio:

700 : 1 (Typ.) (TM)

Designed For:

Desktop Monitor

Response Time:

1.5/3.5 (Typ.)(Tr/Td) Ms

Viewing Angle:

45/45/20/45 (Typ.)(CR≥10)

Supply Ability:

100000 Unit/Units per Month

Product Description

23.6 inch 1920*1080 LCD Screen Display V236HGE-L23 For Desktop Monitor

V236HGE-L23 LCD Panel Product details :

Brand	Chimei Innolux
Model P/N	V236HGE-L23
Diagonal Size	23.6"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1080, FHD 93PPI
Pixel Format	RGB Vertical Stripe
Active Area	521.28(W)×293.22(H) mm
Bezel Opening	525.22(W)×297.22(H) mm
Outline Dim.	544.8×320.2×11.5 (H×V×D)
Treatment	Antiglare (Haze 25%), Hard coating (3H)
Luminance	200 cd/m² (Typ.)
Contrast Ratio	700 : 1 (Typ.) (TM)
View Direction	-
Response Time	1.5/3.5 (Typ.)(Tr/Td) ms
Viewing Angle	45/45/20/45 (Typ.)(CR≥10)
Operating Mode	TN, Normally White, Transmissive
Support Color	16.7M 72% NTSC
Light Source	4 strings WLED , 50K hours , No Driver
Weight	2.31/2.41Kgs (Typ./Max.)
Designed For	Desktop Monitor
Frame Rate	75Hz
Touch Panel	Without
Interface Type	LVDS (2 ch, 8-bit) , Connector 30 pins
Power Supply	5.0V (Typ.)
Environment	Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

V236HGE-L23 LCD Screen Report Item :

Product Overview:

We specialize in the sale of industrial LCD panels and touch screens, offering a wide range of products and technical support. Our inventory includes LCD screens and touch screens from 5.7 inches to 42 inches, suitable for numerous industrial purposes.

Product Information and Services:

Comprehensive Product Information: We provide detailed product information for all types of LCD screens and touch screens, including specifications, features, and compatibility.

Technical Consultation: Our team of experts is available to offer technical consultations, helping you select the right screen for your specific needs and ensuring optimal performance.

Stock and Availability:

Our extensive stock ranges from 5.7 inches to 42 inches, catering to various industrial requirements. Whether you need a display for vehicles, medical equipment, injection molding machines, or other industrial equipment, we have the right solution for you.

Why Choose Us:

Extensive Inventory: A wide range of sizes and specifications to meet diverse industrial needs.

Expert Support: Professional technical consultation to guide you through the selection process.

Quality Assurance: High-quality products designed for durability and reliability in industrial applications.

V236HGE-L23 LCD Panel Shipping and Package :

23.6 inch 1920*1080 LCD Screen Display V236HGE-L23 For Desktop Monitor 0

V236HGE-L23 LCD Screen Shipment Information :

Worldwide Shipping:

We provide global shipping to ensure our products reach customers no matter where they are located.

Standard Shipping by DHL:

Delivery Time: Your order will be shipped via DHL and will typically arrive within 3-7 days.

Customs Fees: Please note that depending on your country's customs policies, additional duty fees may apply.

Expedited Service: DHL offers fast and reliable delivery to most destinations worldwide.

Economical Shipping by HK Post:

Lower Fees: For customers looking to minimize shipping costs and avoid customs fees, we offer the option to ship via Hong Kong Post.

Delivery Time: Shipments via HK Post usually take 15-20 days to arrive.

Customs Handling: Inform us if you prefer this option, and we will assist you in arranging it.

Customs and Import Fees:

Responsibility: Please be aware that we are not responsible for any import fees, remote area charges, taxes, or other customs-related fees that may apply to your shipment.

Policy Awareness: It is the buyer's responsibility to understand their country's customs policies and potential fees before placing an order.

V236HGE-L23 LCD Screen Refund & Return Policy :

Defective Items:

If you receive a defective item, please notify us within 3 days of receiving your order. We will work with you to resolve the issue promptly.

Return Conditions:

Items should be returned in their original packaging whenever possible to ensure they are protected during transit and to facilitate the return process.

Shipping Considerations:

China Post Air Mail: Please note that due to regional weather conditions and other factors, delivery times for China Post Air Mail can range from 10 to 50 days. We appreciate your patience if you choose this shipping method.

V236HGE-L23 LCD Panel FAQ :

Q: Can I pay my goods V236HGE-L23 by credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: How do you ship my goods V236HGE-L23 ?

A: We can shipping all over the world.via DHL,UPS,Fedex and EMS.

Q: Are you manufactory or trade company ?

A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.

Q: Can you give me a discount if I need a large quantity of V236HGE-L23 ?

A: Of course!If you make a large order, we will give you a discount.
