M320QAN01.2 3840*2160 LCD Module 32.0 inch LCD display
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | M320QAN01.2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M320QAN01.2 | Diagonal Size: | 32.0" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 3840(RGB)×2160, UHD 137PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 708.48(W)×398.52(H) Mm |
| Work Mode: | AHVA, Normally Black, Transmissive | Best View On: | Symmetry |
| Backlight: | KSF LED [4 Strings × 2CN], W/O Driver | Used For: | Desktop Monitor |
Product Description
M320QAN01.2 3840*2160 LCD Module 32.0 inch LCD display
M320QAN01.2 LCD Panel Product details :
| Brand | AUO |
| Model P/N | M320QAN01.2 |
| Diagonal Size | 32.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 3840(RGB)×2160, UHD 137PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 708.48(W)×398.52(H) mm |
| Bezel Opening | - |
| Outline Dim. | 721.88(H)×417.93(V)×17.37(D)mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 12 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Support Color | 1.07B 100%Adobe RGB |
| Light Source | KSF LED [4 strings × 2CN], W/O Driver |
| Weight | 3.90Kgs (Typ.) |
| Designed For | Desktop Monitor |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | eDP (8 Lanes) , HBR1 (2.7G/lane) , 41 pinsConnector |
| Power Supply | 12.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
Important Note Regarding M320QAN01.2 LCD Screen:
The part numbers mentioned in the titles serve solely as a reference to aid you in locating a compatible screen for your existing model number. Please be aware that receiving the exact part number as listed in the title is not guaranteed. Instead, we will dispatch a 100% compatible item that matches the specifications of the original part number. It's common for manufacturers to alter part numbers over time, rendering certain numbers obsolete. Furthermore, the images included in the listing are intended for illustrative purposes only, showcasing the connector's position and the fixing points.
M320QAN01.2 LCD Panel Shipping and Package :
Shipping Details for M320QAN01.2 LCD Screen:
Rest assured, your item is in excellent condition and will be carefully prepared for shipping.
All orders will be dispatched to the buyer's specified shipping address as listed during the purchase process. If you wish to have your order delivered to an alternative address, kindly ensure that you update your shipping details accordingly before completing your transaction.
Please note that the seller reserves the right to opt for a shipping company other than the one initially indicated in the listing, at their discretion. Common carriers utilized include USPS, UPS, and FedEx. Should you prefer to use your own shipping label, please feel free to get in touch with us.
Upon shipment, all packages will be provided with a tracking number for your convenience. We extend our shipping services internationally; however, please be advised that the buyer assumes responsibility for all associated international shipping and handling fees.
While we prioritize shipping the model specified in the title, in the event that this model is unavailable, we will promptly dispatch its compatible universal counterpart to fulfill your order.
M320QAN01.2 LCD Panel FAQ :
Q: Can you give me a discount if I need a large quantity of M320QAN01.2 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of M320QAN01.2 ?
A: we will give you tracking number then you can trace your order from website.
Q: How to make payment of M320QAN01.2 ?
A: We accept T/T , Paypal , western union .
Q: Do you accept sample orders of M320QAN01.2 ?
A: Of course!sample order is welcome !
