M215HGJ-L2U 21.5 inch 1920*1080 72%NTSC LCD Screen Monitor
Product Details:
Place of Origin: | China |
Brand Name: | Chimei Innolux |
Model Number: | M215HGJ-L2U |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | M215HGJ-L2U | Diagonal Size: | 21.5" |
---|---|---|---|
Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1920(RGB)×1080, FHD 102PPI |
Pixel Format: | RGB Vertical Stripe | Active Area: | 476.64(W)×268.11(H) Mm |
Application: | Desktop Monitor | Frame Rate: | 60Hz |
Operating Mode: | TN, Normally White, Transmissive | Support Color: | 16.7M 72% NTSC |
Product Description
M215HGJ-L2U 21.5 inch 1920*1080 72%NTSC LCD Screen Monitor
M215HGJ-L2U LCD Panel Product details :
Brand | Chimei Innolux |
Model P/N | M215HGJ-L2U |
Diagonal Size | 21.5" |
Panel Type | a-Si TFT-LCD, LCM |
Resolution | 1920(RGB)×1080, FHD 102PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 476.64(W)×268.11(H) mm |
Bezel Opening | 479.84(W)×271.31(H) mm |
Outline Dim. | 495.6×292.2×9.4 (H×V×D) |
Treatment | Antiglare (Haze 25%), Hard coating (3H) |
Luminance | 250 cd/m² (Typ.) |
Contrast Ratio | 1000 : 1 (Typ.) (TM) |
View Direction | 6 o'clock |
Response Time | 1.5/3.5 (Typ.)(Tr/Td) ms |
Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
Operating Mode | TN, Normally White, Transmissive |
Support Color | 16.7M 72% NTSC |
Light Source | 4 strings WLED , 30K hours , No Driver |
Mass | 1.74/1.81Kgs (Typ./Max.) |
Designed For | Desktop Monitor |
Frame Rate | 60Hz |
Touch Panel | Without |
Signal Type | LVDS (2 ch, 8-bit) , Connector 30 pins |
Voltage Supply | 5.0V (Typ.) |
Environment | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
M215HGJ-L2U LCD Panel Shipping and Package :
M215HGJ-L2U LCD Panel FAQ :
Q: Can you tested the M215HGJ-L2U before shipping ?
A: Of course , our lcd panel M215HGJ-L2U was Strictly tested before shipping.
Q: How to order M215HGJ-L2U ?
A: We accept T/T , Paypal , western union .
Q: How long the warranty of the lcd M215HGJ-L2U ?
A: 90 days .
Q: What happen if the lcd panel M215HGJ-L2U I received can't work ?
A: M215HGJ-L2U was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
