NEW BTL605496-W735L LCD 6.0 inch 540*960 LCD Screen Panel

Brand Name:	BOE
Model Number:	BTL605496-W735L
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

BTL605496-W735L

Diagonal Size:

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

540(RGB)×960, QHD 184PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

74.52(W)×132.48(H) Mm

Application:

Mobile Phone

Touch Screen:

Without

Supply Ability:

100000 Unit/Units per Month

Product Description

NEW BTL605496-W735L LCD 6.0 inch 540*960 LCD Screen Panel

BTL605496-W735L LCD Panel Product details :

Brand	BOE
Model P/N	BTL605496-W735L
Diagonal Size	6.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	540(RGB)×960, qHD 184PPI
Pixel Format	RGB Vertical Stripe
Active Area	74.52(W)×132.48(H) mm
Bezel Opening	-
Outline Size	78.32(W)×141.2(H)×2.35(D) mm
Brightness	400 cd/m² (Typ.)
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Best View on	Symmetry
Display Colors	16.7M 71%NTSC
Frequency	60Hz
Weight	45.0g (Typ.)
Surface	Antiglare
Contrast Ratio	800:1 (Typ.) (TM)
Display Mode	ADS, Normally Black, Transmissive
Response Time	25 (Typ.)(Tr+Td)
Lamp Type	6S2P WLED, Without Driver
Touch Screen	Without
Application	Mobile Phone
Signal Interface	MIPI (2 data lanes), 30 pinsConnector
Input Voltage	1.8/2.8V (Typ.)(IOVCC/VCI)
Environment	Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C
