LP173WD1-TLN2 17.3 inch Laptop LCD Screen Display Panel
  • name
  • name

LP173WD1-TLN2 17.3 inch Laptop LCD Screen Display Panel

Brand Name: LG
Model Number: LP173WD1-TLN2
MOQ: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Payment Terms: T/T, Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Model Name:
LP173WD1-TLN2
Diagonal Size:
17.3"
Panel Type:
A-Si TFT-LCD, LCM
Resolution:
1600(RGB)×900, HD+ 106PPI
Pixel Format:
RGB Vertical Stripe
Active Area:
381.888(W)×214.812(H) Mm
Display Mode:
TN, Normally White, Transmissive
Display Colors:
262K 57%NTSC
Backlight:
WLED, 12K Hours, With LED Driver
Application:
Laptop
Supply Ability:
100000 Unit/Units per Month
Product Description

LP173WD1-TLN2 17.3 inch Laptop LCD Screen Display Panel



LP173WD1-TLN2 LCD Panel Product details :



Brand LG Display
Model P/N LP173WD1-TLN2
Diagonal Size 17.3"
Panel Type a-Si TFT-LCD, LCM
Resolution 1600(RGB)×900, HD+ 106PPI
Pixel Format RGB Vertical Stripe
Active Area 381.888(W)×214.812(H) mm
Bezel Opening 384.89(W)×217.81(H) mm
Outline Dim. 398.1(H)×232.8(V)×6(D)mm
Treatment Glare (Haze 0%)
Luminance 200 cd/m² (Typ.)
Contrast Ratio 600:1 (Typ.) (TM)
View Direction 6 o'clock
Response Time 8 (Typ.)(Tr+Td)
Viewing Angle 40/40/10/30 (Min.)(CR≥10)
Operating Mode TN, Normally White, Transmissive
Support Color 262K 57%NTSC
Light Source WLED, 12K hours, With LED Driver
Form Style Wedge (PCBA Bent, T≥5.2mm)
Designed For Laptop
Frame Rate 60Hz
Touch Panel Without
Interface Type LVDS (2 ch, 6-bit), 40 pinsConnector
Power Supply 3.3V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
LP173WD1-TLN2 17.3 inch Laptop LCD Screen Display Panel

LP173WD1-TLN2 LCD Panel Shipment  :

· We're not responsible for any accidents delays or other issues that are the resposibility of the shipping service.But we will help you to track the package until you get.

· Please make sure to double check your address before completing your payment.

· An email will be sent as package is process for shipment .We will provide tracking number for you to check the package online.

· Customers are responsible for customs taxes and duties where applicable.

· Any import charges or fees are the buyer's responsibility. If the package can't be delivered because of the buyers reason(including refusing to sign), buyer should afford all the extra cost!


LP173WD1-TLN2 LCD Panel Shipping and Package :

LP173WD1-TLN2 17.3 inch Laptop LCD Screen Display Panel 0


LP173WD1-TLN2 LCD Panel Shipment Information :

Shipment Policies
Responsibility for Delays and Issues: While we are committed to helping you track your package, please note that we are not responsible for any accidents, delays, or other issues that are the responsibility of the shipping service. We will, however, assist you in tracking your package until it reaches you.

Address Verification: It is crucial to double-check your shipping address before completing your payment. Ensuring that the address is accurate helps prevent delivery issues and delays.

Shipping Notification: Once your package is processed for shipment, you will receive an email notification. This email will include the tracking number, which you can use to monitor your package's status online.

Customs Taxes and Duties: Customers are responsible for any customs taxes and duties applicable in their country. Please be aware of your local regulations regarding import charges to avoid unexpected fees.

Import Charges: Any additional import charges or fees imposed by your country are the buyer's responsibility. If a package cannot be delivered due to reasons attributable to the buyer (such as refusal to sign for the package), the buyer will be responsible for any additional costs incurred.


LP173WD1-TLN2 LCD Panel Return and Warranty Information :


Return Policy
Inspection and Exchange: All goods undergo two inspections before shipment to guarantee quality. If you are not satisfied with your purchase, you may exchange the item within one week. To initiate an exchange, please contact us within 24 hours of receiving your purchase.

Condition of Return Items: Items must be returned in their original condition, including the box and all accessories. Items showing signs of man-made defects, such as breakage or scratches, are not eligible for return or exchange.

Return Shipping: For returning any items, please use EMS (Express Mail Service) or your local postal service to send the item back to us.

Warranty Policy
Warranty Duration: All items come with a six-month warranty, covering any issues not caused by human error or damage. If your item has a defect not caused by man-made problems, we will replace it for you free of charge.

Best After-Sale Service: We pride ourselves on providing excellent after-sale service. Should any problems arise, we are dedicated to resolving them to ensure customer satisfaction.


LP173WD1-TLN2 LCD Panel FAQ :



Q: Can You declare my order of LP173WD1-TLN2 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .



Q: How long is the warranty ?

A: We offer 90days warranty .



Q: Can I pay my order of LP173WD1-TLN2via credit card ?

A: Yes!you can use your credit card through your Paypal account.



Q: How long will I receive my goods LP173WD1-TLN2 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
