HSD055BHW6-P00 5.5 inch 720*1440 LCD Display Screen Panel

HSD055BHW6-P00 5.5 inch 720*1440 LCD Display Screen Panel

Product Details:

Place of Origin: China
Brand Name: HannStar
Model Number: HSD055BHW6-P00

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 100000 Unit/Units per Month
Get Best Price Contact Now

Detail Information

Model Name: HSD055BHW6-P00 Diagonal Size: 5.5"
Panel Type: A-Si TFT-LCD, CELL, Q-CUT (Full Cell) Resolution: 720(RGB)×1440 295PPI
Pixel Format: RGB Vertical Stripe Display Mode: IPS Pro, Normally Black, Transmissive
Plate Thickness: 0.20+0.20 Mm Support Color: 16.7M 70%NTSC
Light Source: No B/L Designed For: Mobile Phone

Product Description

HSD055BHW6-P00 5.5 inch 720*1440 LCD Display Screen Panel



HSD055BHW6-P00 LCD Panel Product details :



Brand HannStar
Model P/N HSD055BHW6-P00
Diagonal Size 5.5"
Panel Type a-Si TFT-LCD, CELL, Q-CUT (Full Cell)
Resolution 720(RGB)×1440 295PPI
Pixel Format RGB Vertical Stripe
Active Area 61.884(W)×123.768(H) mm
Bezel Opening -
Outline Dim. 63.884(H)×129.458(V)×0.8(D) mm
Treatment Without Polarizer
Luminance 0 cd/m²
Contrast Ratio 1000:1 (Typ.) (TM)
View Direction Symmetry
Response Time 25 (Typ.)(Tr+Td)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10)
Operating Mode IPS Pro, Normally Black, Transmissive
Plate Thickness 0.20+0.20 mm
Transmittance 11.3% (Typ.)(without Polarizer)
Support Color 16.7M 70%NTSC
Light Source No B/L
Weight -
Designed For Mobile Phone
Frame Rate -
Touch Panel Without
D-IC Detail COG Suggest HX8394F, NT35521Z, ILI9881C, OTM120A, JD9365D, OTM1287A, OTM1289A, OTM1290A-CH11, NT35521S
Environment Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C



HSD055BHW6-P00 LCD Panel Attention:

Before placing an order for purchase, the buyer must confirm the screen model needs.

If you are not sure about the model of the screen, please contact us at the first time.

We will distinguish and prevent you from buying the wrong screen.

If the buyer's mistake let screen make the screen unusable, all the freight incurred shall be borne by the buyer.


HSD055BHW6-P00 LCD Panel Shipping and Package :

HSD055BHW6-P00 5.5 inch 720*1440 LCD Display Screen Panel 0

HSD055BHW6-P00 LCD Panel Return and Refund:


At our company, we strive to provide our customers with the best products and services. However, we understand that sometimes mistakes can happen or a product may not meet your expectations. Therefore, we have a straightforward return and refund policy to ensure your satisfaction.



If for any reason you have purchased the wrong item or the product is not suitable for your needs, we are happy to facilitate a return for you. Just let us know within a reasonable timeframe, and we will provide you with instructions on how to return the item.



Once we receive the returned item, we will promptly issue a refund to the original payment method. Our goal is to make the return and refund process as smooth and hassle-free as possible for you.



We value your business and want you to feel confident when shopping with us. Therefore, we stand behind our products and services, and we will do everything we can to make things right for you.



Thank you for choosing our company, and we hope to have the opportunity to assist you with all of your future needs.



HSD055BHW6-P00 LCD Panel Return Note :

Model Confirmation: When placing an order for our LCD screen, please ensure that the model number matches exactly with the one you intend to replace. This is crucial to avoid purchasing the wrong product that may not function properly in your device.

Installation Caution: Before confirming that the screen does not work properly, refrain from using adhesive to attach our screen to your equipment. If adhesive is applied and the screen is installed, we regret that we cannot accept returns or provide refunds. This precaution is essential to ensure that our products remain in their original condition for potential troubleshooting or returns.

HSD055BHW6-P00 LCD Panel FAQ :



Q: Do you accept sample orders of HSD055BHW6-P00 ?

A: Of course!sample order is welcome !



Q: Can you give me a discount if I need a large quantity of HSD055BHW6-P00 ?

A: Of course!If you make a large order, we will give you a discount.



Q: How long will I receive my goods HSD055BHW6-P00 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.



Q: Can I pay my order of HSD055BHW6-P00 via credit card ?

A: Yes!you can use your credit card through your Paypal account.
