HSD052BHW1-P00 5.2 inch 720*1280 TFT-LCD Display Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD052BHW1-P00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD052BHW1-P00 | Diagonal Size: | 5.2" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL, Q-CUT (Full Cell) | Resolution: | 720(RGB)×1280, WXGA 282PPI |
| Pixel Format: | RGB Vertical Stripe | Display Mode: | IPS Pro, Normally Black, Transmissive |
| Plate Thickness: | 0.40+0.40 Mm | Transmittance: | 3.3% (Typ.)(with Polarizer) |
| Support Color: | 16.7M 70%NTSC | Designed For: | Mobile Phone |
Product Description
HSD052BHW1-P00 5.2 inch 720*1280 TFT-LCD Display Screen
HSD052BHW1-P00 LCD Panel Product details :
| Brand | HannStar |
| Model P/N | HSD052BHW1-P00 |
| Diagonal Size | 5.2" |
| Panel Type | a-Si TFT-LCD, CELL, Q-CUT (Full Cell) |
| Resolution | 720(RGB)×1280, WXGA 282PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 64.8(W)×115.2(H) mm |
| Bezel Opening | - |
| Outline Dim. | 66.8(H)×121.2(V)×0.8(D) mm |
| Treatment | With Polarizer |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 14/16 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | IPS Pro, Normally Black, Transmissive |
| Plate Thickness | 0.40+0.40 mm |
| Transmittance | 3.3% (Typ.)(with Polarizer) |
| Support Color | 16.7M 70%NTSC |
| Light Source | No B/L |
| Weight | - |
| Designed For | Mobile Phone |
| Frame Rate | - |
| Touch Panel | Without |
| D-IC Detail | COG Suggest OTM1284A, OTM1289A, HX8394F, ILI9881C, R61350, NT35521S, JD9365 |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
HSD052BHW1-P00 LCD Panel Shipping and Package :
At our company, we understand the importance of purchasing in bulk, especially when it comes to fulfilling large orders for your business needs. That's why we offer bulk order assistance to help make the process easy and hassle-free for you.
Whether you need additional items to be added to your original order or if you require a much larger quantity, our dedicated team is always ready to assist you. We will work closely with you to ensure that your needs are met efficiently and promptly, without sacrificing quality or customer satisfaction.
You can rest assured that our team will go above and beyond to provide you with the best possible service and support throughout the entire bulk ordering process. So, if you require a larger quantity than initially specified, don't hesitate to reach out to us - we're here to help you every step of the way!
Q: Can you tested the HSD052BHW1-P00 before shipping ?
A: Of course , our lcd panel HSD052BHW1-P00 was Strictly tested before shipping.
Q: How to order HSD052BHW1-P00 ?
A: We accept T/T , Paypal , western union .
Q: What happen if the lcd panel HSD052BHW1-P00 received can't work ?
A:HSD052BHW1-P00 was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
