5.7 inch HSD057BHW1-P00 720*1440 LCD Screen Monitor
  • name

5.7 inch HSD057BHW1-P00 720*1440 LCD Screen Monitor

Brand Name: HannStar
Model Number: HSD057BHW1-P00
MOQ: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Payment Terms: T/T, Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Model Name:
HSD057BHW1-P00
Diagonal Size:
5.7"
Panel Type:
A-Si TFT-LCD, CELL, Q-CUT (Full Cell)
Resolution:
720(RGB)×1440 282PPI
Pixel Format:
RGB Vertical Stripe
Work Mode:
IPS Pro, Normally Black, Transmissive
Best View On:
Symmetry
Response Time:
10/20 (Typ.)(Tr/Td)
Transmissivity:
3.5% (Typ.)(with Polarizer)
Application:
Mobile Phone
Supply Ability:
100000 Unit/Units per Month
Product Description

5.7 inch HSD057BHW1-P00 720*1440 LCD Screen Monitor



HSD057BHW1-P00 LCD Panel Product details :



Brand HannStar
Model P/N HSD057BHW1-P00
Diagonal Size 5.7"
Panel Type a-Si TFT-LCD, CELL, Q-CUT (Full Cell)
Resolution 720(RGB)×1440 282PPI
Pixel Format RGB Vertical Stripe
Active Area 64.8(W)×129.6(H) mm
Bezel Opening -
Outline Size 66.8(W)×135.29(H)×0.8(D) mm
Surface Without Polarizer
Brightness 0 cd/m²
Contrast Ratio 1000:1 (Typ.) (TM)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10)
Display Mode IPS Pro, Normally Black, Transmissive
Best View on Symmetry
Response Time 10/20 (Typ.)(Tr/Td)
Glass Depth 0.40+0.40 mm
Transmissivity 3.5% (Typ.)(with Polarizer)
Display Colors 16.7M 68%NTSC
Lamp Type No B/L
Frequency -
Touch Screen Without
Driver IC COG Suggest HX8394F, ILI9881C, JD365D, OTM1289A_B6
Panel Weight -
Application Mobile Phone
Environment Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C



HSD057BHW1-P00 LCD Panel Attention:

Before placing an order for purchase, the buyer must confirm the screen model needs.

If you are not sure about the model of the screen, please contact us at the first time.

We will distinguish and prevent you from buying the wrong screen.

If the buyer's mistake let screen make the screen unusable, all the freight incurred shall be borne by the buyer.


HSD057BHW1-P00 LCD Panel Shipping and Package :

5.7 inch HSD057BHW1-P00 720*1440 LCD Screen Monitor 0

HSD057BHW1-P00 LCD Panel Shipping Information :

Shipping Agency: We utilize a reputable and efficient shipping agency known for its reliability and professionalism. Our goal is to ensure fast and secure delivery of your order.

Delivery Time: Typically, our standard delivery time ranges from 3 to 7 business days for shipments worldwide. This timeframe is subject to regional variations and potential delays beyond our control.

Additional Charges: Please note that import duties, taxes, and other related charges are not included in the item price or shipping charges. These charges, if applicable, are the responsibility of the buyer and may be assessed upon delivery by customs authorities in the destination country.

HSD057BHW1-P00 LCD Panel Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.
Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

HSD057BHW1-P00 LCD Panel FAQ :



Q: Do you accept sample orders of HSD057BHW1-P00 ?

A: Of course! Sample order is welcome.



Q: Can I pay my order of HSD057BHW1-P00 vai credit card?

A: Yes! You can use your credit card through your Paypal account.



Q: How long is the warranty ?

A: We offer 90 days warranty.



Q: If I place order now, when will you ship the goods of HSD057BHW1-P00 ?

A: The order will be shipped within 2-3 working days after received your payment.
