6.1 inch HSD061BHF1-P00 720*1560 LCD FOR Mobile Phone
Product Details:
| Place of Origin: | China |
| Brand Name: | HannStar |
| Model Number: | HSD061BHF1-P00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | HSD061BHF1-P00 | Diagonal Size: | 6.1" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL, Q-CUT (Full Cell) | Resolution: | 720(RGB)×1560 282PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 64.8(W)×140.4(H) Mm |
| Designed For: | Mobile Phone | Environment: | Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -40 ~ 80 °C |
| Display Colors: | 16.7M 71%NTSC | Lamp Type: | No B/L |
Product Description
6.1 inch HSD061BHF1-P00 720*1560 LCD FOR Mobile Phone
HSD061BHF1-P00 LCD Panel Product details :
| Brand | HannStar |
| Model P/N | HSD061BHF1-P00 |
| Diagonal Size | 6.1" |
| Panel Type | a-Si TFT-LCD, CELL, Q-CUT (Full Cell) |
| Resolution | 720(RGB)×1560 282PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 64.8(W)×140.4(H) mm |
| Bezel Opening | - |
| Outline Size | 66.6(W)×145.3(H)×0.8(D) mm |
| Surface | - |
| Brightness | 0 cd/m² |
| Contrast Ratio | 1600:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Display Mode | IPS Pro, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 26 (Max.)(Tr+Td) |
| Glass Depth | 0.40+0.40 mm |
| Transmissivity | 4.0% (Typ.) |
| Display Colors | 16.7M 71%NTSC |
| Lamp Type | No B/L |
| Frequency | - |
| Touch Screen | Without |
| Driver IC | COG Suggest HX8394, JD9365D, ILI9881C-04, OTM1290A |
| Panel Weight | - |
| Application | Mobile Phone |
| Environment | Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -40 ~ 80 °C |
HSD061BHF1-P00 LCD Panel Attention:
Before placing an order for purchase, the buyer must confirm the screen model needs.
If you are not sure about the model of the screen, please contact us at the first time.
We will distinguish and prevent you from buying the wrong screen.
If the buyer's mistake let screen make the screen unusable, all the freight incurred shall be borne by the buyer.
HSD061BHF1-P00 LCD Panel Shipping and Package :
HSD061BHF1-P00 LCD Panel Shipping Information :
Shipping Agency: We utilize a reputable and efficient shipping agency known for its reliability and professionalism. Our goal is to ensure fast and secure delivery of your order.
Delivery Time: Typically, our standard delivery time ranges from 3 to 7 business days for shipments worldwide. This timeframe is subject to regional variations and potential delays beyond our control.
Additional Charges: Please note that import duties, taxes, and other related charges are not included in the item price or shipping charges. These charges, if applicable, are the responsibility of the buyer and may be assessed upon delivery by customs authorities in the destination country.
HSD061BHF1-P00 LCD Panel Return Note :
Model Confirmation: When placing an order for our LCD screen, please ensure that the model number matches exactly with the one you intend to replace. This is crucial to avoid purchasing the wrong product that may not function properly in your device.
Installation Caution: Before confirming that the screen does not work properly, refrain from using adhesive to attach our screen to your equipment. If adhesive is applied and the screen is installed, we regret that we cannot accept returns or provide refunds. This precaution is essential to ensure that our products remain in their original condition for potential troubleshooting or returns.
HSD061BHF1-P00 LCD Panel FAQ :
Q: How to order lcd panel HSD061BHF1-P00 ?
A: We accept T/T , Paypal , western union .
Q: Can you tested the HSD061BHF1-P00 before shipping ?
A: Of course , lcd screen HSD061BHF1-P00 was Strictly tested before shipping.
Q: What happen if the HSD061BHF1-P00 received can't work ?
A: HSD061BHF1-P00 lcd panel was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
Q: How long the warranty of the HSD061BHF1-P00 ?
A: 90 days .
