LCD Screen Display Panel

LQ024B7UD01 2.4 inch 24 pins TFT LCD Screen Display

All Category

Floor Standing Digital Signage

LQ024B7UD01 2.4 inch 24 pins TFT LCD Screen Display

Brand Name:	Sharp
Model Number:	LQ024B7UD01
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LQ024B7UD01

Diagonal Size:

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

160(RGB)×240, HQVGA 120PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

33.6(W)×50.4(H) Mm

Application:

Mobile Phone、Handheld & PDA

Touch Screen:

Without

Supply Ability:

100000 Unit/Units per Month

Product Description

LQ024B7UD01 2.4 inch 24 pins TFT LCD Screen Display

LQ024B7UD01 LCD Panel Product details :

Brand	Sharp
Model P/N	LQ024B7UD01
Diagonal Size	2.4"
Panel Type	a-Si TFT-LCD, LCM
Resolution	160(RGB)×240, HQVGA 120PPI
Pixel Format	RGB Vertical Stripe
Active Area	33.6(W)×50.4(H) mm
Bezel Opening	-
Outline Dim.	41.8(H)×66.6(V)×4.55(D) mm
Treatment	Hard coating (3H)
Luminance	28 cd/m² (Typ.)
Contrast Ratio	110:1 (Typ.) (TM) 12:1 (Typ.) (RF)
View Direction	6 o'clock
Response Time	30/50 (Typ.)(Tr/Td)
Viewing Angle	50/50/60/50 (Typ.)(CR≥10)
Operating Mode	TN, Normally White, Transflective
Support Color	65K
Light Source	WLED [2S1P], W/O Driver
Weight	18.0g
Designed For	Mobile Phone,Handheld & PDA
Frame Rate	-
Touch Panel	Without
Interface Type	CPU, 24 pinsConnector
Power Supply	3.3V (Typ.)
Environment	Operating Temperature: -10 ~ 60 °C; Storage Temperature: -20 ~ 70 °C
LQ024B7UD01 2.4 inch 24 pins TFT LCD Screen Display

LQ024B7UD01 LCD Panel Attention:

Before placing an order for purchase, the buyer must confirm the screen model needs.

If you are not sure about the model of the screen, please contact us at the first time.

We will distinguish and prevent you from buying the wrong screen.

If the buyer's mistake let screen make the screen unusable, all the freight incurred shall be borne by the buyer.

LQ024B7UD01 LCD Panel Shipping and Package :

LQ024B7UD01 LCD Panel Shipping Information :

Shipping Agency: We utilize a reputable and efficient shipping agency known for its reliability and professionalism. Our goal is to ensure fast and secure delivery of your order.

Delivery Time: Typically, our standard delivery time ranges from 3 to 7 business days for shipments worldwide. This timeframe is subject to regional variations and potential delays beyond our control.

Additional Charges: Please note that import duties, taxes, and other related charges are not included in the item price or shipping charges. These charges, if applicable, are the responsibility of the buyer and may be assessed upon delivery by customs authorities in the destination country.

LQ024B7UD01 LCD Panel Return Note :

Model Confirmation: When placing an order for our LCD screen, please ensure that the model number matches exactly with the one you intend to replace. This is crucial to avoid purchasing the wrong product that may not function properly in your device.

Installation Caution: Before confirming that the screen does not work properly, refrain from using adhesive to attach our screen to your equipment. If adhesive is applied and the screen is installed, we regret that we cannot accept returns or provide refunds. This precaution is essential to ensure that our products remain in their original condition for potential troubleshooting or returns.

LQ024B7UD01 LCD Panel FAQ :

Q: Can You declare my order of LQ024B7UD01 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: How long is the warranty ?

A: We offer 90days warranty .

Q: Can I pay my order of LQ024B7UD01 via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: Can you give me a discount if I need a large quantity of LQ024B7UD01 ?

A: Of course!If you make a large order, we will give you a discount.
