LCD Screen Display Panel

LK816D3LA19 1080*1920 82 inch LCD screen for Digital Signage

All Category

Floor Standing Digital Signage

LK816D3LA19 1080*1920 82 inch LCD screen for Digital Signage

Brand Name:	Sharp
Model Number:	LK816D3LA19
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LK816D3LA19

Diagonal Size:

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1080×1920(RGB), FHD 27PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

1015.74(W)×1805.76(H) Mm

Application:

Digital Signage、Outdoor High Brightness

Touchscreen:

Without

Supply Ability:

100000 Unit/Units per Month

Product Description

LK816D3LA19 1080*1920 82 inch LCD screen for Digital Signage

LK816D3LA19 LCD Panel Product details :

Brand	Sharp
Model P/N	LK816D3LA19
Diagonal Size	82"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1080×1920(RGB), FHD 27PPI
Pixel Format	RGB Horizontal Stripe
Active Area	1015.74(W)×1805.76(H) mm
Bezel Opening	1023.2(W)×1812.6(H) mm
Outline Size	1094(W)×1879(H)×82.9(D) mm
Surface	Antiglare, Hard coating (2H), Antireflection
Brightness	1200 cd/m² (Typ.)
Contrast Ratio	1500:1 (Typ.) (TM)
Viewing Angle	88/88/88/88 (Typ.)(CR≥10)
Display Mode	ASV, Normally Black, Transmissive
Best View on	Symmetry
Response Time	6 (Typ.)(G to G)
Display Colors	16.7M 55%NTSC
Lamp Type	120 pcsCCFL, 60K hours, With Inverter
Frequency	60Hz
Touch Screen	Without
Panel Weight	64.8±1.0Kgs
Application	Digital Signage,Outdoor High Brightness
Signal Interface	LVDS (2 ch, 8-bit), 55 pinsConnector
Input Voltage	12.0V (Typ.)
Environment	Operating Temp.: -10 ~ 35 °C ; Storage Temp.: -25 ~ 60 °C
LK816D3LA19 1080*1920 82 inch LCD screen for Digital Signage

LK816D3LA19 Pre-Order Check:

Before proceeding with your order, kindly verify if your machine model is compatible with this specific LCD screen. If you're uncertain, please reach out to us, and we'll promptly assist you.

Note:

Some of the screen backplates may not be entirely new, potentially showing signs of dirt or adhesive residue. Please take note of this!

LK816D3LA19 LCD Panel Shipping and Package :

LK816D3LA19 Shipping Information:

Please ensure that the model you've ordered matches exactly with the model you require. We will ship according to the model specified in your order.

Verify that the shipping address provided is accurate. Shipments will be sent to the address listed on the order. If you need delivery to a different address, please email us immediately after making the payment.

Shipments will be processed within 3 business days of receiving payment.

Each LCD panel undergoes rigorous testing before shipping, ensuring quality. Additionally, we take utmost care in packaging to ensure safe delivery.

LCD screens will be shipped using EMS/DHL/UPS based on location or customer preference.

Attention to Russian Customers:

For shipments to Russia, we can only use EMS. Please note that EMS delivery typically takes longer to arrive. We appreciate your patience during this time.

LK816D3LA19 About the Goods:

Upon receiving your item, please confirm receipt. In the event that the item is damaged, kindly contact us immediately. Send us a photo of the damage so we can assess the situation and offer you the best solution.

While we guarantee timely delivery, please note that we do not have control over the express delivery time. Our dedicated sales staff will dispatch the Air Waybill (AWB) for your delivered goods on the following business day. You can track the AWB on the designated website provided to you. Alternatively, you can inquire about the AWB by contacting your local branch of the courier company handling the shipment.

LK816D3LA19 LCD Panel FAQ :

Q: How to make payment of LK816D3LA19 ?

A: We accept T/T , Paypal , western union .

Q: If I place order now,when will you ship the goods of LK816D3LA19 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can you give me a discount if I need a large quantity of LK816D3LA19 ?

A: Of course!If you make a large order, we will give you a discount.

Q: How long will I receive my goods LK816D3LA19 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
