M156B1-C01 1366*768 15.6 inch 60Hz LCD Screen Panel

Brand Name:	CMO
Model Number:	M156B1-C01
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

M156B1-C01

Diagonal Size:

15.6"

Panel Type:

A-Si TFT-LCD, CELL, Full Cell

Resolution:

1366(RGB)×768, WXGA 100PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

344.232(W)×193.536(H) Mm

Touch Screen:

Without

Application:

Desktop Monitor

Supply Ability:

100000 Unit/Units per Month

Product Description

M156B1-C01 1366*768 15.6 inch 60Hz LCD Screen Panel

M156B1-C01 LCD Panel Product details :

Brand	CMO
Model P/N	M156B1-C01
Diagonal Size	15.6"
Panel Type	a-Si TFT-LCD, CELL, Full Cell
Resolution	1366(RGB)×768, WXGA 100PPI
Pixel Format	RGB Vertical Stripe
Active Area	344.232(W)×193.536(H) mm
Bezel Opening	-
Outline(mm)	353.632 × 203.068× 1.83 (H×V×D)
Treatment	Antiglare (Haze 25%), Hard coating (3H)
Luminance	0 cd/m²
Contrast Ratio	500 : 1 (Typ.) (TM)
Viewing Angle	45/45/20/45 (Typ.)(CR≥10)
Response	2/6 (Typ.)(Tr/Td) ms
Good View at	6 o'clock
Work Mode	TN, Normally White, Transmissive
Glass Thickness	0.70+0.70 mm
Transmissivity	11.0% (Typ.)(with Polarizer)
Color Depth	16.7M 66%NTSC
Backlight	No B/L
Mass	297g (Typ.)
Used for	Desktop Monitor
Refresh Rate	60Hz
Touchscreen	Without
Max. Ratings	Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

M156B1-C01 Pre-Order Check:

Before proceeding with your order, kindly verify if your machine model is compatible with this specific LCD screen. If you're uncertain, please reach out to us, and we'll promptly assist you.

Note:

Some of the screen backplates may not be entirely new, potentially showing signs of dirt or adhesive residue. Please take note of this!

M156B1-C01 LCD Panel Shipping and Package :

M156B1-C01 Shipping Information:

Please ensure that the model you've ordered matches exactly with the model you require. We will ship according to the model specified in your order.

Verify that the shipping address provided is accurate. Shipments will be sent to the address listed on the order. If you need delivery to a different address, please email us immediately after making the payment.

Shipments will be processed within 3 business days of receiving payment.

Each LCD panel undergoes rigorous testing before shipping, ensuring quality. Additionally, we take utmost care in packaging to ensure safe delivery.

LCD screens will be shipped using EMS/DHL/UPS based on location or customer preference.

Attention to Russian Customers:

For shipments to Russia, we can only use EMS. Please note that EMS delivery typically takes longer to arrive. We appreciate your patience during this time.

M156B1-C01 About the Goods:

Upon receiving your item, please confirm receipt. In the event that the item is damaged, kindly contact us immediately. Send us a photo of the damage so we can assess the situation and offer you the best solution.

While we guarantee timely delivery, please note that we do not have control over the express delivery time. Our dedicated sales staff will dispatch the Air Waybill (AWB) for your delivered goods on the following business day. You can track the AWB on the designated website provided to you. Alternatively, you can inquire about the AWB by contacting your local branch of the courier company handling the shipment.

M156B1-C01 LCD Panel FAQ :

Q: Do you accept sample orders of M156B1-C01 ?

A: Of course! Sample order is welcome.

Q: Can I pay my order of M156B1-C01 vai credit card?

A: Yes! You can use your credit card through your Paypal account.

Q: How long is the warranty ?

A: We offer 90 days warranty.

Q: If I place order now, when will you ship the goods of M156B1-C01 ?

A: The order will be shipped within 2-3 working days after received your payment.
