NEW 1280*800 N133I6-P01 13.3 inch 60Hz LCD Screen Module
Product Details:
Place of Origin: | China |
Brand Name: | CMO |
Model Number: | N133I6-P01 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | N133I6-P01 | Diagonal Size: | 13.3" |
---|---|---|---|
Panel Type: | A-Si TFT-LCD, CELL, FOB | Resolution: | 1280(RGB)×800, WXGA 113PPI |
Pixel Format: | RGB Vertical Stripe | Active Area: | 286.08(W)×178.8(H) Mm |
Touch Screen: | Without | Application: | Laptop |
Product Description
NEW 1280*800 N133I6-P01 13.3 inch 60Hz LCD Screen Module
N133I6-P01 LCD Panel Product details :
Brand | CMO |
Model P/N | N133I6-P01 |
Diagonal Size | 13.3" |
Panel Type | a-Si TFT-LCD, CELL, FOB |
Resolution | 1280(RGB)×800, WXGA 113PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 286.08(W)×178.8(H) mm |
Bezel Opening | - |
Brightness | 0 cd/m² |
Contrast Ratio | 500:1 (Typ.) (TM) |
Viewing Angle | 45/45/20/45 (Typ.)(CR≥10) |
Display Mode | TN, Normally White, Transmissive |
Best View on | 6 o'clock |
Response Time | 3/5 (Typ.)(Tr/Td) |
Glass Depth | - |
Transmissivity | 8.0% (Typ.)(with Polarizer) |
Display Colors | 262K 43%NTSC |
Lamp Type | No B/L |
Frequency | 60Hz |
Touch Screen | Without |
Driver IC | COG Built-in 8 source + 3 gate chips |
Shape Style | Flat (PCBA Flat, T3.4~4.0mm) |
Application | Laptop |
Signal Interface | LVDS (1 ch, 6-bit), 30 pins Connector |
Input Voltage | 3.3V (Typ.) |
Environment | Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C |
N133I6-P01 LCD Panel Shipping and Package :
Q: How long will I receive my goods N133I6-P01 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q:If I place order now,when will you ship the goods of N133I6-P01 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q:Do you accept sample orders of N133I6-P01 ?
A:Of course!sample order is welcome !
Q: How long is the warranty ?
A: We offer 90days warranty .
