LCD Screen Display Panel

480*272 A050FW02 V1 5.0 inch LCD Screen Monitor

All Category

Floor Standing Digital Signage

480*272 A050FW02 V1 5.0 inch LCD Screen Monitor

Brand Name:	AUO
Model Number:	A050FW02 V1
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

A050FW02 V1

Diagonal Size:

Panel Type:

A-Si TFT-LCD, CELL, FOG

Resolution:

480(RGB)×272, WQVGA 109PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

110.88(W)×62.832(H) Mm

Touch Panel:

Without

Designed For:

MP3 PMP

Supply Ability:

100000 Unit/Units per Month

Product Description

480*272 A050FW02 V1 5.0 inch LCD Screen Monitor

A050FW02 V1 LCD Panel Product details :

Brand	AUO
Model P/N	A050FW02 V1
Diagonal Size	5.0"
Panel Type	a-Si TFT-LCD, CELL, FOG
Resolution	480(RGB)×272, WQVGA 109PPI
Pixel Format	RGB Vertical Stripe
Active Area	110.88(W)×62.832(H) mm
Bezel Opening	-
Outline Dim.	116.5(W)×71.8(H)×1.43(D) mm
Luminance	0 cd/m²
View Direction	6 o'clock
Viewing Angle	65/65/50/65 (Typ.)(CR≥10)
Plate Thickness	0.50+0.50 mm
Support Color	16.7M 54% NTSC
Weight	18.1g (Typ.)
Frame Rate	-
Treatment	Antiglare, Hard coating (3H)
Contrast Ratio	300:1 (Typ.) (TM)
Response Time	7/23 (Typ.)(Tr/Td)
Operating Mode	TN, Normally White, Transmissive
Transmittance	7.0% (Typ.)(with Polarizer)
Light Source	No B/L
Designed For	MP3 PMP
Touch Panel	Without
D-IC Detail	COG Built-in 1 source chips
Interface Type	Parallel RGB (1 ch, 8-bit)40 pins FPC
Power Supply	3.3V (Typ.)(VDD)
Environment	Operating Temperature: -30 ~ 70 °C; Storage Temperature: -40 ~ 80 °C

A050FW02 V1 Pre-Order Check:

Before proceeding with your order, kindly verify if your machine model is compatible with this specific LCD screen. If you're uncertain, please reach out to us, and we'll promptly assist you.

Note:

Some of the screen backplates may not be entirely new, potentially showing signs of dirt or adhesive residue. Please take note of this!

A050FW02 V1 LCD Panel Shipping and Package :

A050FW02 V1 Shipping Information:

Please ensure that the model you've ordered matches exactly with the model you require. We will ship according to the model specified in your order.

Verify that the shipping address provided is accurate. Shipments will be sent to the address listed on the order. If you need delivery to a different address, please email us immediately after making the payment.

Shipments will be processed within 3 business days of receiving payment.

Each LCD panel undergoes rigorous testing before shipping, ensuring quality. Additionally, we take utmost care in packaging to ensure safe delivery.

LCD screens will be shipped using EMS/DHL/UPS based on location or customer preference.

Attention to Russian Customers:

For shipments to Russia, we can only use EMS. Please note that EMS delivery typically takes longer to arrive. We appreciate your patience during this time.

A050FW02 V1 About the Goods:

Upon receiving your item, please confirm receipt. In the event that the item is damaged, kindly contact us immediately. Send us a photo of the damage so we can assess the situation and offer you the best solution.

While we guarantee timely delivery, please note that we do not have control over the express delivery time. Our dedicated sales staff will dispatch the Air Waybill (AWB) for your delivered goods on the following business day. You can track the AWB on the designated website provided to you. Alternatively, you can inquire about the AWB by contacting your local branch of the courier company handling the shipment.

A050FW02 V1 LCD Panel FAQ :

Q: How can I trace my order of A050FW02 V1 ?

A: we will give you tracking number then you can trace your order from website.

Q: How to make payment of A050FW02 V1 ?

A: We accept T/T , Paypal , western union .

Q: Do you accept sample orders of A050FW02 V1 ?

A: Of course!sample order is welcome !

Q: Can you give me a discount if I need a large quantity of A050FW02 V1 ?

A: Of course!If you make a large order, we will give you a discount.
