720*1600 QM065HS03-1 6.5 inch tft LCD Screen

Brand Name:	HKC
Model Number:	QM065HS03-1
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

QM065HS03-1

Diagonal Size:

Panel Type:

A-Si TFT-LCD, CELL , Q-CUT (Full Cell)

Resolution:

720(RGB)×1600 269PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

67.932(W)×150.96(H) Mm

Operating Mode:

HSI, Normally Black, Transmissive

Designed For:

Mobile Phone

Support Color:

16.7M 70% NTSC

Frame Rate:

Supply Ability:

100000 Unit/Units per Month

Highlight:

QM065HS03-1

QM065HS03-1 tft LCD Screen

6.5 inch tft LCD Screen

Product Description

720*1600 QM065HS03-1 6.5 inch tft LCD Screen

QM065HS03-1 LCD Panel Product details :

Brand	HKC
Model P/N	QM065HS03-1
Diagonal Size	6.5"
Panel Type	a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Resolution	720(RGB)×1600 269PPI
Pixel Format	RGB Vertical Stripe
Active Area	67.932(W)×150.96(H) mm
Bezel Opening	-
Outline Dim.	69.932(H)×155.96(V) ×0.8(D) mm
Treatment	Without Polarizer
Luminance	0 cd/m²
Contrast Ratio	1500:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	30 (Typ.)(Tr+Td)
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Operating Mode	HSI, Normally Black, Transmissive
Plate Thickness	0.40+0.40 mm
Transmittance	3.3% (Typ.)
Support Color	16.7M 70% NTSC
Light Source	No B/L
Weight	22.6g (Max.)
Designed For	Mobile Phone
Frame Rate	60Hz
Touch Panel	Without
D-IC Detail	COG Suggest NT36525B, GC7202H, FT8006S_AN, AXS15209, FT8006S_AA, TF8006S_AB
Environment	Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -40 ~ 80 °C

QM065HS03-1 Pre-Order Check:

Before proceeding with your order, kindly verify if your machine model is compatible with this specific LCD screen. If you're uncertain, please reach out to us, and we'll promptly assist you.

Note:

Some of the screen backplates may not be entirely new, potentially showing signs of dirt or adhesive residue. Please take note of this!

QM065HS03-1 LCD Panel Shipping and Package :

QM065HS03-1 Shipping Information:

Please ensure that the model you've ordered matches exactly with the model you require. We will ship according to the model specified in your order.

Verify that the shipping address provided is accurate. Shipments will be sent to the address listed on the order. If you need delivery to a different address, please email us immediately after making the payment.

Shipments will be processed within 3 business days of receiving payment.

Each LCD panel undergoes rigorous testing before shipping, ensuring quality. Additionally, we take utmost care in packaging to ensure safe delivery.

LCD screens will be shipped using EMS/DHL/UPS based on location or customer preference.

Attention to Russian Customers:

For shipments to Russia, we can only use EMS. Please note that EMS delivery typically takes longer to arrive. We appreciate your patience during this time.

QM065HS03-1 About the Goods:

Upon receiving your item, please confirm receipt. In the event that the item is damaged, kindly contact us immediately. Send us a photo of the damage so we can assess the situation and offer you the best solution.

While we guarantee timely delivery, please note that we do not have control over the express delivery time. Our dedicated sales staff will dispatch the Air Waybill (AWB) for your delivered goods on the following business day. You can track the AWB on the designated website provided to you. Alternatively, you can inquire about the AWB by contacting your local branch of the courier company handling the shipment.

QM065HS03-1 LCD Panel FAQ :

Q: How to make payment of QM065HS03-1 ?

A: We accept T/T , Paypal , western union .

Q: Can you give me a discount if I need a large quantity of QM065HS03-1 ?

A: Of course!If you make a large order, we will give you a discount.

Q: Can You declare my order of QM065HS03-1 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: Can I pay my order of QM065HS03-1 via credit card ?

A: Yes!you can use your credit card through your Paypal account.
