LCD Touch Panel Display

LP101WX1-SLB1 40 pins 60Hz 10.1 inch LCD Display

All Category

Floor Standing Digital Signage

LP101WX1-SLB1 40 pins 60Hz 10.1 inch LCD Display

Brand Name:	LG
Model Number:	LP101WX1-SLB1
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LP101WX1-SLB1

Diagonal Size:

10.1"

Resolution:

1280(RGB)×800, WXGA 149PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

216.96(W)×135.6(H) Mm

Viewing Angle:

80/80/80/80 (Min.)(CR≥10)

Display Colors:

262K 50%NTSC

Lamp Type:

WLED, 15K Hours, With LED Driver

Application:

Pad & Tablet

Signal Interface:

LVDS (1 Ch, 6-bit), 40 PinsConnector

Supply Ability:

100000 Unit/Units per Month

Product Description

LP101WX1-SLB1 40 pins 60Hz 10.1 inch LCD Display

LP101WX1-SLB1 LCD Panel Product details :

Brand	LG Display
Model P/N	LP101WX1-SLB1
Diagonal Size	10.1"
Panel Type	a-Si TFT-LCD, Assembly
Resolution	1280(RGB)×800, WXGA 149PPI
Pixel Format	RGB Vertical Stripe
Active Area	216.96(W)×135.6(H) mm
Bezel Opening	-
Outline Size	262.7(W)×178.7(H)×7.1(D) mm
Treatment	Anti Fingerprint
Luminance	340 cd/m² (Typ.)
Contrast Ratio	500 : 1 (Min.) (TM)
Viewing Angle	80/80/80/80 (Min.)(CR≥10)
Response	35 (Typ.)(Tr+Td) ms
Good View at	Symmetry
Work Mode	-
Color Depth	262K 50%NTSC
Backlight	WLED, 15K hours, With LED Driver
Mass	300g (Max.)
Used for	Pad & Tablet
Refresh Rate	60Hz
Touchscreen	PCAP, USB
Signal Type	LVDS (1 ch, 6-bit), 40 pinsConnector
Voltage Supply	3.3V (Typ.)
Max. Ratings	Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
LP101WX1-SLB1 40 pins 60Hz 10.1 inch LCD Display

LP101WX1-SLB1 Pre-Order Check:

Before proceeding with your order, kindly verify if your machine model is compatible with this specific LCD screen. If you're uncertain, please reach out to us, and we'll promptly assist you.

Note:

Some of the screen backplates may not be entirely new, potentially showing signs of dirt or adhesive residue. Please take note of this!

LP101WX1-SLB1 LCD Panel Shipping and Package :

LP101WX1-SLB1 Shipping Information:

Please ensure that the model you've ordered matches exactly with the model you require. We will ship according to the model specified in your order.

Verify that the shipping address provided is accurate. Shipments will be sent to the address listed on the order. If you need delivery to a different address, please email us immediately after making the payment.

Shipments will be processed within 3 business days of receiving payment.

Each LCD panel undergoes rigorous testing before shipping, ensuring quality. Additionally, we take utmost care in packaging to ensure safe delivery.

LCD screens will be shipped using EMS/DHL/UPS based on location or customer preference.

Attention to Russian Customers:

For shipments to Russia, we can only use EMS. Please note that EMS delivery typically takes longer to arrive. We appreciate your patience during this time.

LP101WX1-SLB1 About the Goods:

Upon receiving your item, please confirm receipt. In the event that the item is damaged, kindly contact us immediately. Send us a photo of the damage so we can assess the situation and offer you the best solution.

While we guarantee timely delivery, please note that we do not have control over the express delivery time. Our dedicated sales staff will dispatch the Air Waybill (AWB) for your delivered goods on the following business day. You can track the AWB on the designated website provided to you. Alternatively, you can inquire about the AWB by contacting your local branch of the courier company handling the shipment.

LP101WX1-SLB1 LCD Panel FAQ :

Q: Can You declare my order of LP101WX1-SLB1 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: Can you give me a discount if I need a large quantity of LP101WX1-SLB1 ?

A: Of course!If you make a large order, we will give you a discount.

Q: Can I pay my order of LP101WX1-SLB1 via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: How long will I receive my goods LP101WX1-SLB1 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
