LP101WSA-TLN1 10.1 inch 45%NTSC Lcd Panel Monitor

Brand Name:	LG
Model Number:	LP101WSA-TLN1
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LP101WSA-TLN1

Diagonal Size:

10.1"

Resolution:

1024(RGB)×600, WSVGA 117PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

222.72(W)×125.28(H) Mm

Display Mode:

TN, Normally White, Transmissive

Display Colors:

262K 45%NTSC

Lamp Type:

WLED, 10K Hours, With LED Driver

Application:

Netbook PC

Signal Interface:

LVDS (1 Ch, 6-bit), 40 PinsConnector

Supply Ability:

100000 Unit/Units per Month

Product Description

LP101WSA-TLN1 10.1 inch 45%NTSC Lcd Panel Monitor

LP101WSA-TLN1 LCD Panel Product details :

Brand	LG Display
Model P/N	LP101WSA-TLN1
Diagonal Size	10.1"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1024(RGB)×600, WSVGA 117PPI
Pixel Format	RGB Vertical Stripe
Active Area	222.72(W)×125.28(H) mm
Bezel Opening	226.0(W)×128.7(H) mm
Outline(mm)	235 × 143× 5.2 (H×V×D)
Treatment	Glare (Haze 0%)
Luminance	200 cd/m² (Typ.)
Contrast Ratio	300 : 1 (Min.) (TM)
Viewing Angle	30/30/10/20 (Min.)(CR≥10)
Response	16 (Typ.)(Tr+Td) ms
Good View at	6 o'clock
Work Mode	TN, Normally White, Transmissive
Color Depth	262K 45%NTSC
Backlight	WLED, 10K hours, With LED Driver
Outline Shape	Wedge (PCBA Bent, T≥5.2mm)
Used for	Netbook PC
Refresh Rate	60Hz
Touchscreen	Without
Signal Type	LVDS (1 ch, 6-bit), 40 pinsConnector
Voltage Supply	3.3V (Typ.)
Max. Ratings	Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
LP101WSA-TLN1 10.1 inch 45%NTSC Lcd Panel Monitor

LP101WSA-TLN1 Pre-Order Check:

Before proceeding with your order, kindly verify if your machine model is compatible with this specific LCD screen. If you're uncertain, please reach out to us, and we'll promptly assist you.

Note:

Some of the screen backplates may not be entirely new, potentially showing signs of dirt or adhesive residue. Please take note of this!

LP101WSA-TLN1 LCD Panel Shipping and Package :

LP101WSA-TLN1 Shipping Information:

Please ensure that the model you've ordered matches exactly with the model you require. We will ship according to the model specified in your order.

Verify that the shipping address provided is accurate. Shipments will be sent to the address listed on the order. If you need delivery to a different address, please email us immediately after making the payment.

Shipments will be processed within 3 business days of receiving payment.

Each LCD panel undergoes rigorous testing before shipping, ensuring quality. Additionally, we take utmost care in packaging to ensure safe delivery.

LCD screens will be shipped using EMS/DHL/UPS based on location or customer preference.

Attention to Russian Customers:

For shipments to Russia, we can only use EMS. Please note that EMS delivery typically takes longer to arrive. We appreciate your patience during this time.

LP101WSA-TLN1 About the Goods:

Upon receiving your item, please confirm receipt. In the event that the item is damaged, kindly contact us immediately. Send us a photo of the damage so we can assess the situation and offer you the best solution.

While we guarantee timely delivery, please note that we do not have control over the express delivery time. Our dedicated sales staff will dispatch the Air Waybill (AWB) for your delivered goods on the following business day. You can track the AWB on the designated website provided to you. Alternatively, you can inquire about the AWB by contacting your local branch of the courier company handling the shipment.

LP101WSA-TLN1 LCD Panel FAQ :

Q: Can I pay my order of LP101WSA-TLN1 via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: If I place order now,when will you ship the goods of LP101WSA-TLN1 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can You declare my order of LP101WSA-TLN1 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: How long will I receive my goods LP101WSA-TLN1 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
