DJ080EA-01G 8.0 inch LCD screen 800*480 TFT LCD Display

Brand Name:	Innolux
Model Number:	DJ080EA-01G
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

DJ080EA-01G

Diagonal Size:

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

800(RGB)×480, WVGA 116PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

174(W)×104.4(H) Mm

Display Colors:

262K/16.7M 65%NTSC

Application:

Automotive Display

Best View On:

Symmetry

Frequency:

Supply Ability:

100000 Unit/Units per Month

Product Description

DJ080EA-01G 8.0 inch LCD screen 800*480 TFT LCD Display

DJ080EA-01G LCD Panel Product details :

Brand	Innolux
Model P/N	DJ080EA-01G
Diagonal Size	8.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	800(RGB)×480, WVGA 116PPI
Pixel Format	RGB Vertical Stripe
Active Area	174(W)×104.4(H) mm
Bezel Opening	177.4(W)×107.8(H) mm
Outline Size	191.8(W)×120.7(H)×19.5(D) mm
Surface	Antiglare
Brightness	650 cd/m² (Typ.)
Contrast Ratio	2000:1 (Typ.) (TM)
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Display Mode	VA, Normally Black, Transmissive
Best View on	Symmetry
Response Time	16/6 (Typ.)(Tr/Td)
Display Colors	262K/16.7M 65%NTSC
Lamp Type	WLED, With LED Driver
Frequency	60Hz
Touch Screen	Without
Panel Weight	370±37g
Application	Automotive Display
Signal Interface	Parallel RGB (1 ch, 6/8-bit) + SPI, 55 pinsConnector
Input Voltage	3.3V (Typ.)
Environment	Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C

DJ080EA-01G LCD Panel Pre-order Checklist :

Compatibility Verification:

Prior to placing your order, kindly verify if this LCD screen is compatible with your specific machine model. Should you have any doubts or require assistance, please do not hesitate to reach out to us for clarification.

Contact Information and Address Details:

Please ensure that your phone number, complete address, and zip code are accurate and up to date before proceeding with your order placement.

DJ080EA-01G LCD Panel Shipping and Package :

DJ080EA-01G LCD Panel Delivery Details :

Dispatch Timeframe:

Your ordered items will be dispatched within 7 working days following confirmation of payment.

Shipping Options:

The method of shipping will be determined based on the shipping cost option you select during checkout. Please choose a shipping method that best suits your requirements and budget.

Additional Charges for Remote Areas:

If your delivery address is situated in a remote area, there may be additional charges incurred. We will promptly inform you if any adjustments to the shipping cost are necessary due to the location of your delivery address.

DJ080EA-01G LCD Panel After-Sales Service Policy :

Return Policy:

We offer a 5-day return window without the need for providing reasons. If you wish to return the item within this period, please contact us. Please note that the shipping cost for the return will be covered by the buyer.

Warranty Coverage:

This item is covered by a 90-day warranty. However, certain damages resulting from human error or natural disasters are not included in our warranty coverage. Examples of such exclusions include improper installation, physical damage (such as scratches or broken screens), mishandling, and power surges.

Warranty Void Conditions:

Products sold in our store come with fragile warranty tags. If these tags are tampered with or removed during the warranty period, the warranty will be considered void. Additionally, any disconnection or loss of the item will result in the forfeiture of the warranty, and we will not assume responsibility in such cases.

Please be mindful of these terms and conditions when availing of our after-sales services. Should you have any questions or require assistance, do not hesitate to reach out to us for further clarification.

DJ080EA-01G LCD Panel FAQ :

Q: How can I trace my order of DJ080EA-01G ?

A: we will give you tracking number then you can trace your order from website.

Q: Can you give me a discount if I need a large quantity of DJ080EA-01G ?

A: Of course!If you make a large order, we will give you a discount.

Q: Can I pay my order of DJ080EA-01G via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: How long will I receive my goods DJ080EA-01G ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
