LM240WU3-TLD1 24.0 inch 1920*1200 LCD Panel Module

Brand Name:	LG Display
Model Number:	LM240WU3-TLD1
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LM240WU3-TLD1

Diagonal Size:

24.0"

Resolution:

1920(RGB)×1200, WUXGA 94PPI

Active Area:

518.4(W)×324(H) Mm

Viewing Angle:

85/85/75/85 (Typ.)(CR≥10)

Operating Mode:

TN, Normally White, Transmissive

Support Color:

16.7M 92%NTSC

Light Source:

6 Pcs CCFL , 40K Hours , Without Driver

Application:

Desktop Monitor

Interface Type:

LVDS (2 Ch, 8-bit), 30 PinsConnector

Supply Ability:

100000 Unit/Units per Month

Product Description

LM240WU3-TLD1 24.0 inch 1920*1200 LCD Panel Module

LM240WU3-TLD1 LCD Panel Product details :

Brand	LG Display
Model P/N	LM240WU3-TLD1
Diagonal Size	24.0"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1920(RGB)×1200, WUXGA 94PPI
Pixel Format	RGB Vertical Stripe
Active Area	518.4(W)×324(H) mm
Bezel Opening	522.4(W)×328.0(H) mm
Outline Size	546.4(W)×352(H)×36.2(D) mm
Brightness	400 cd/m² (Typ.)
Viewing Angle	85/85/75/85 (Typ.)(CR≥10)
Best View on	6 o'clock
Display Colors	16.7M 92%NTSC
Frequency	60Hz
Weight	2.48/2.60Kgs (Typ./Max.)
Surface	Antiglare, Hard coating (3H)
Contrast Ratio	1000:1 (Typ.) (TM)
Display Mode	TN, Normally White, Transmissive
Response Time	5 (Typ.)(Tr+Td)
Lamp Type	6 pcs CCFL , 40K hours , Without Driver
Touch Screen	Without
Application	Desktop Monitor
Signal Interface	LVDS (2 ch, 8-bit), 30 pinsConnector
Input Voltage	5.0V (Typ.)
Environment	Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
LM240WU3-TLD1 24.0 inch 1920*1200 LCD Panel Module

LM240WU3-TLD1 LCD Screen About Us:

At our store, we prioritize quality and customer satisfaction. Before shipping out any product, we meticulously test each item to ensure it meets our high standards. Upon receiving your order, we urge you to promptly inspect and use the product.

In the rare event that the product does not function properly or arrives damaged, we kindly request that you reach out to us directly. By contacting us, you allow us the opportunity to swiftly address any issues without the need for opening a CASE, which can have detrimental effects on our store's reputation and prolong the resolution process significantly.

As dedicated sellers, we take full responsibility for resolving any problems you encounter with our products. Your satisfaction is our top priority, and we are committed to working with you until the issue is fully resolved.

Therefore, we encourage you to contact us directly should you experience any difficulties or concerns with your purchase. We are here to assist you every step of the way.

LM240WU3-TLD1 LCD Screen Payment:

For your convenience, we accept a variety of payment methods, including PayPal and all major credit cards such as Visa, MasterCard, ALI, and Discover. When placing your order, you'll find a dropdown menu where you can select the specific model and, if applicable, the color variation.

Should you need to modify or cancel your order, you have the right to do so before it enters the shipping process. Simply reach out to us, and we'll assist you with the necessary steps. However, once the order has been shipped, we are unable to cancel it. In such cases, please contact us, and we'll work together to find a suitable solution to meet your needs.

LM240WU3-TLD1 LCD Panel Shipping and Package :

LM240WU3-TLD1 LCD Screen Shipping:

Please ensure that the address provided is accurate and deliverable. We cannot be held responsible for undeliverable addresses. In the event of items being returned due to an incorrect address, we reserve the right to charge a shipping fee to resend the items.

Orders are typically processed and shipped within 5 business days following the clearance of your payment. Please note that shipments are not made on Saturdays, Sundays, or holidays.

Our standard shipping method is airmail, which is reliable and cost-effective. For those requiring urgent delivery, we also offer international Express options such as EMS. Please be aware that opting for Express delivery may incur an additional shipping fee.

While we strive to ensure prompt delivery, the speed of shipping is beyond our control. Generally, shipments take between 10 to 35 working days to reach most countries, excluding peak periods and special holidays. If you have not received your order within one month, please don't hesitate to contact us for assistance.

Your satisfaction with our shipping services is important to us, and we're here to help address any concerns you may have regarding the delivery of your order.

LM240WU3-TLD1 LCD Panel FAQ :

Q: How long will I receive my goods LM240WU3-TLD1 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

Q: Can you give me a discount if I need a large quantity of LM240WU3-TLD1 ?

A: Of course!If you make a large order, we will give you a discount.

Q: Do you accept sample orders of LM240WU3-TLD1 ?

A: Of course!sample order is welcome !

Q: How long is the warranty ?

A: We offer 90days warranty .
