TX31D201VM0BAA 12.3 inch 1280*480 LCD Screen Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | KOE |
| Model Number: | TX31D201VM0BAA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TX31D201VM0BAA | Diagonal Size: | 12.3" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1280(RGB)×480, DVGA 111PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 291.84(W)×109.44(H) Mm |
| Application: | Industrial | Input Voltage: | 3.3V (Typ.) |
Product Description
TX31D201VM0BAA 12.3 inch 1280*480 LCD Screen Panel
TX31D201VM0BAA LCD Panel Product details :
| Brand | KOE |
| Model P/N | TX31D201VM0BAA |
| Diagonal Size | 12.3" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)×480, DVGA 111PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 291.84(W)×109.44(H) mm |
| Bezel Opening | 295.44(W)×113.04(H) mm |
| Outline Size | 320(W)×130(H)×12.6(D) mm |
| Brightness | 500 cd/m² (Typ.) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 70%NTSC |
| Frequency | 60Hz |
| Weight | 540g |
| Surface | - |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | IPS, Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td) |
| Lamp Type | 4 strings WLED , 70K hours , Without Driver |
| Touch Screen | Without |
| Application | Industrial |
| Signal Interface | LVDS (1 ch, 8-bit), 20 pinsConnector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -30 ~ 80 °C ;Storage Temp.: -40 ~ 90 °C |
| TX31D201VM0BAA 12.3 inch 1280*480 LCD Screen Panel | |
TX31D201VM0BAA LCD Screen About Us:
At our store, we prioritize quality and customer satisfaction. Before shipping out any product, we meticulously test each item to ensure it meets our high standards. Upon receiving your order, we urge you to promptly inspect and use the product.
In the rare event that the product does not function properly or arrives damaged, we kindly request that you reach out to us directly. By contacting us, you allow us the opportunity to swiftly address any issues without the need for opening a CASE, which can have detrimental effects on our store's reputation and prolong the resolution process significantly.
As dedicated sellers, we take full responsibility for resolving any problems you encounter with our products. Your satisfaction is our top priority, and we are committed to working with you until the issue is fully resolved.
Therefore, we encourage you to contact us directly should you experience any difficulties or concerns with your purchase. We are here to assist you every step of the way.
TX31D201VM0BAA LCD Screen Payment:
For your convenience, we accept a variety of payment methods, including PayPal and all major credit cards such as Visa, MasterCard, ALI, and Discover. When placing your order, you'll find a dropdown menu where you can select the specific model and, if applicable, the color variation.
Should you need to modify or cancel your order, you have the right to do so before it enters the shipping process. Simply reach out to us, and we'll assist you with the necessary steps. However, once the order has been shipped, we are unable to cancel it. In such cases, please contact us, and we'll work together to find a suitable solution to meet your needs.
TX31D201VM0BAA LCD Panel Shipping and Package :
TX31D201VM0BAA LCD Screen Shipping:
Please ensure that the address provided is accurate and deliverable. We cannot be held responsible for undeliverable addresses. In the event of items being returned due to an incorrect address, we reserve the right to charge a shipping fee to resend the items.
Orders are typically processed and shipped within 5 business days following the clearance of your payment. Please note that shipments are not made on Saturdays, Sundays, or holidays.
Our standard shipping method is airmail, which is reliable and cost-effective. For those requiring urgent delivery, we also offer international Express options such as EMS. Please be aware that opting for Express delivery may incur an additional shipping fee.
While we strive to ensure prompt delivery, the speed of shipping is beyond our control. Generally, shipments take between 10 to 35 working days to reach most countries, excluding peak periods and special holidays. If you have not received your order within one month, please don't hesitate to contact us for assistance.
Your satisfaction with our shipping services is important to us, and we're here to help address any concerns you may have regarding the delivery of your order.
TX31D201VM0BAA LCD Panel FAQ :
Q: Can you give me a discount if I need a large quantity of TX31D201VM0BAA ?
A: Of course!If you make a large order, we will give you a discount.
Q: How to make payment of TX31D201VM0BAA ?
A: We accept T/T , Paypal , western union .
Q: How can I trace my order of TX31D201VM0BAA ?
A: we will give you tracking number then you can trace your order from website.
Q: Can You declare my order of TX31D201VM0BAA to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
