Industrial LCD Panel Display

TX16D209VM0BAB 6.4 inch LCD Screen Display Panel For KOE

All Category

Floor Standing Digital Signage

TX16D209VM0BAB 6.4 inch LCD Screen Display Panel For KOE

Brand Name:	KOE
Model Number:	TX16D209VM0BAB
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

TX16D209VM0BAB

Diagonal Size:

Panel Type:

A-Si TFT-LCD, LCM

Resolution:

1024(RGB)×768, XGA 200PPI

Pixel Format:

RGB Vertical Stripe

Active Area:

129.792(W)×97.344(H) Mm

Brightness:

1400 Cd/m² (Typ.)

Contrast Ratio:

1500:1 (Typ.) (TM)

Application:

Industrial

Input Voltage:

3.3V (Typ.)

Supply Ability:

100000 Unit/Units per Month

Product Description

TX16D209VM0BAB 6.4 inch LCD Screen Display Panel For KOE

TX16D209VM0BAB LCD Panel Product details :

Brand	KOE
Model P/N	TX16D209VM0BAB
Diagonal Size	6.4"
Panel Type	LTPS TFT-LCD, LCM
Resolution	1024(RGB)×768, XGA 200PPI
Pixel Format	RGB Vertical Stripe
Active Area	129.792(W)×97.344(H) mm
Bezel Opening	132.8(W)×100.34(H) mm
Outline Dim.	153(H)×118(V)×9.2(D) mm
Treatment	Glare (Haze 0%)
Luminance	1400 cd/m² (Typ.)
Contrast Ratio	1500:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	30 (Typ.)(Tr+Td)
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Operating Mode	IPS, Normally Black, Transmissive
Support Color	16.7M 60%NTSC
Light Source	WLED, 70K hours, With LED Driver
Weight	190g (Typ.)
Designed For	Industrial
Frame Rate	60Hz
Touch Panel	Without
Interface Type	LVDS (1 ch, 8-bit), 20 pinsConnector
Power Supply	3.3V (Typ.)
Environment	Operating Temperature: -30 ~ 80 °C; Storage Temperature: -30 ~ 80 °C; Vibration Level: 2.0G (19.6 m/s²)
TX16D209VM0BAB 6.4 inch LCD Screen Display Panel For KOE

TX16D209VM0BAB lcd panel About Us:

At YONGS , we are dedicated to fulfilling the following commitments:

Quality Assurance: We prioritize manufacturing top-tier consumer goods, guaranteeing the utmost quality in every product we deliver. Our commitment to excellence ensures that our customers receive only the best.

Global Reach: We strive to deliver our goods swiftly and accurately to customers worldwide. Whether you're located locally or across the globe, we ensure fast and precise delivery to meet your needs.

Your satisfaction is our priority, and we aim to exceed expectations in every aspect of our service.

TX16D209VM0BAB LCD Panel Shipping and Package :

TX16D209VM0BAB LCD Panel Delivery :

We are committed to dispatching your order promptly. Upon confirmation of payment, we will process and ship your items within 5 working days.

The shipping method will be determined by the option you select based on shipping costs. Therefore, please choose the most suitable shipping method based on your individual requirements.

Please be aware that if your delivery address is in a remote area, additional charges may apply. Should there be any changes to the shipping cost, we will promptly inform you of the revised amount before proceeding with delivery.

TX16D209VM0BAB LCD Panel After-Service:

We provide a 90-day warranty for this item. However, please note that the cost of returning the item is the responsibility of the buyer.

Our warranty does not cover damage caused by human error or natural disasters. This includes instances such as improper installation, physical damage (e.g., scratches, cracks), mishandling, or tampering with warranty tags during the warranty period. Any disconnection or loss of the product will be considered as relinquishing the warranty, and we will not be liable for any associated issues.

Please take note of these terms to ensure a smooth and efficient after-sales experience.

TX16D209VM0BAB LCD Panel FAQ :

Q: How to do if I can't find the screen that I require in your listings?

A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .

Q: Why big order delivery time are long?

A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!

Q:Can you declared low value for my order when shipping?

A:Yes, We can do it for you if you need.

Q: What happen if the lcd panel TX16D209VM0BAB I received can't work ?

A: All the goods will be tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.
