LCD Screen Display Panel

LM185WH1-TLA1 18.5 inch LCD Screen Display Panel

All Category

Floor Standing Digital Signage

LM185WH1-TLA1 18.5 inch LCD Screen Display Panel

Brand Name:	LG Display
Model Number:	LM185WH1-TLA1
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LM185WH1-TLA1

Diagonal Size:

18.5"

Resolution:

1366(RGB)×768, WXGA 84PPI

Active Area:

409.8(W)×230.4(H) Mm

Outline Dim.:

430.4(H)×254.6(V)×13.5(D) Mm

Luminance:

300 Cd/m² (Typ.)

Contrast Ratio:

1000:1 (Typ.) (TM)

Designed For:

Desktop Monitor

Frame Rate:

Interface Type:

LVDS (2 Ch, 8-bit), 30 PinsConnector

Supply Ability:

100000 Unit/Units per Month

Product Description

LM185WH1-TLA1 18.5 inch LCD Screen Display Panel

LM185WH1-TLA1 LCD Panel Product details :

Brand	LG Display
Model P/N	LM185WH1-TLA1
Diagonal Size	18.5"
Panel Type	a-Si TFT-LCD, LCM
Resolution	1366(RGB)×768, WXGA 84PPI
Pixel Format	RGB Vertical Stripe
Active Area	409.8(W)×230.4(H) mm
Bezel Opening	413.4(W)×234.0(H) mm
Outline Dim.	430.4(H)×254.6(V)×13.5(D) mm
Treatment	Antiglare, Hard coating (3H)
Luminance	300 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.) (TM)
View Direction	6 o'clock
Response Time	1.1/3.9 (Typ.)(Tr/Td)
Viewing Angle	85/85/75/85 (Typ.)(CR＞10)
Operating Mode	TN, Normally White, Transmissive
Support Color	16.7M 72%NTSC
Light Source	CCFL [2 pcs], 50K hours, W/O Driver
Weight	1.55Kgs (Typ.)
Designed For	Desktop Monitor
Frame Rate	60Hz
Touch Panel	Without
Interface Type	LVDS (2 ch, 8-bit), 30 pinsConnector
Power Supply	5.0V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
LM185WH1-TLA1 18.5 inch LCD Screen Display Panel

LM185WH1-TLA1 lcd panel About Us:

At YONGS , we are dedicated to fulfilling the following commitments:

Quality Assurance: We prioritize manufacturing top-tier consumer goods, guaranteeing the utmost quality in every product we deliver. Our commitment to excellence ensures that our customers receive only the best.

Global Reach: We strive to deliver our goods swiftly and accurately to customers worldwide. Whether you're located locally or across the globe, we ensure fast and precise delivery to meet your needs.

Your satisfaction is our priority, and we aim to exceed expectations in every aspect of our service.

LM185WH1-TLA1 LCD Panel Shipping and Package :

LM185WH1-TLA1 LCD Panel Delivery :

We are committed to dispatching your order promptly. Upon confirmation of payment, we will process and ship your items within 5 working days.

The shipping method will be determined by the option you select based on shipping costs. Therefore, please choose the most suitable shipping method based on your individual requirements.

Please be aware that if your delivery address is in a remote area, additional charges may apply. Should there be any changes to the shipping cost, we will promptly inform you of the revised amount before proceeding with delivery.

LM185WH1-TLA1 LCD Panel After-Service:

We provide a 90-day warranty for this item. However, please note that the cost of returning the item is the responsibility of the buyer.

Our warranty does not cover damage caused by human error or natural disasters. This includes instances such as improper installation, physical damage (e.g., scratches, cracks), mishandling, or tampering with warranty tags during the warranty period. Any disconnection or loss of the product will be considered as relinquishing the warranty, and we will not be liable for any associated issues.

Please take note of these terms to ensure a smooth and efficient after-sales experience.

LM185WH1-TLA1 LCD Panel FAQ :

Q: How to order LG lcd panel LM185WH1-TLA1 ?

A: We accept T/T , Paypal , western union .

Q: Can you tested the LM185WH1-TLA1 before shipping ?

A: Of course , 18.5 inch lcd screen LM185WH1-TLA1 was Strictly tested before shipping.

Q: What happen if the LM185WH1-TLA1 received can't work ?

A: LM185WH1-TLA1 lcd panel was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .

Q: How long the warranty of the LM185WH1-TLA1 ?

A: 90 days .
