MV238FHB-N62 LCD Display Panel 23.8 inch LCD Screen Module
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | MV238FHB-N62 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | MV238FHB-N62 | Diagonal Size: | 23.8" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, CELL , FOB | Resolution: | 1920(RGB)×1080, FHD 92PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 527.04(W)×296.46(H) Mm |
| Display Colors: | 16.7M 100% SRGB | Lamp Type: | No B/L , W/O Driver |
| Frequency: | 75Hz | Application: | Desktop Monitor |
Product Description
MV238FHB-N62 LCD Display Panel 23.8 inch LCD Screen Module
MV238FHB-N62 LCD Panel Product details :
| Brand | BOE |
| Model P/N | MV238FHB-N62 |
| Diagonal Size | 23.8" |
| Panel Type | a-Si TFT-LCD, CELL , FOB |
| Resolution | 1920(RGB)×1080, FHD 92PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 527.04(W)×296.46(H) mm |
| Bezel Opening | - |
| Outline Size | 534.84(H)×307.76(V) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Brightness | 0 cd/m² |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Plate Thickness | - |
| Transmittance | 5.3% (Typ.)(with Polarizer) |
| Best View on | Symmetry |
| Response Time | 14 (Typ.)(G to G) |
| Display Colors | 16.7M 100% sRGB |
| Lamp Type | No B/L , W/O Driver |
| Frequency | 75Hz |
| Touch Screen | Without |
| Weight | TBD |
| Application | Desktop Monitor |
| D-IC Detail | COF Built-in 8 source chips |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
MV238FHB-N62 LCD Screen Buying Guide:
To enhance your shopping experience and ensure the compatibility of your purchase, consider the following helpful information:
1. Match Size, Resolution, and Backlight:
Ensure that the LCD screen you are purchasing matches the size, resolution, and backlight specifications of your original screen. This information is crucial for a seamless replacement and optimal performance. Review the product details carefully to confirm these specifications before making a purchase.
2. Uncertain? Contact Us for Expert Assistance:
If you are unsure about the compatibility of the LCD screen, don't hesitate to reach out to us. Contact our customer support with details such as your LCD brand, serial/model number, or the model number on the back of your current screen. Our dedicated technicians are available to assist you in choosing the correct screen for your specific needs.
3. Provide LCD Details for Accurate Assistance:
When seeking assistance, providing additional details about your existing LCD can significantly aid our technicians in guiding you to the right product. Include information such as the brand, serial/model number, or any other relevant details. This allows us to offer precise recommendations tailored to your device.
4. Expert Guidance for Correct Screen Selection:
Our team of technicians is ready to provide expert guidance to ensure you select the correct LCD screen. Whether you need assistance with understanding technical specifications or have questions about compatibility, we are here to help. Feel free to rely on our expertise to make an informed purchase.
MV238FHB-N62 LCD Panel Shipping and Package :
MV238FHB-N62 LCD Screen Shipping Information:
1. Full Name and Detailed Address Requirement:
To ensure accurate and timely delivery, kindly provide the full name of the consignee and a detailed shipping address. This information is crucial for the shipping process and helps prevent any delays or complications. Please review and confirm the accuracy of this information before finalizing your order.
2. Address Change Protocol:
We ship exclusively to the delivery address specified in the order. If there is a need to change the shipping address, we kindly request that you contact us in advance. This proactive communication allows us to update the shipping details and ensures that your order reaches the correct destination without any issues.
3. Buyer's Responsibility for Customs Fees and Taxes:
Please be aware that the buyer is responsible for all additional costs associated with customs, including but not limited to customs fees, brokerage fees, customs duties, and taxes applicable in your country. These charges may vary depending on your location and the specific regulations of your country's customs department.
4. Important Notice:
It is essential for buyers to be aware of and prepared for potential customs-related fees and taxes. These charges are beyond our control and are determined by the customs authorities in the destination country. We recommend checking with your local customs office to understand the applicable fees and regulations.
MV238FHB-N62 LCD Screen Return Policy:
1. Mandatory Notification for Returns:
For all return requests, it is imperative to inform us in advance. The buyer is required to notify the seller of the intention to return items within 7 days after receiving the package. We reserve the right to refuse any return request that exceeds this stipulated 7-day time frame.
2. Exchange Policy for Buyer Error:
In instances where the buyer has ordered the wrong part, an exchange can be facilitated, but the buyer is responsible for the 2-ways shipping fee. This policy ensures that buyers are attentive and accurate when placing orders to avoid unnecessary shipping costs.
3. Condition of Return Items:
Return items must be in their original packaging and in good condition. It is essential that all components, accessories, and documentation are included with the returned product. This requirement helps maintain the integrity of the return process and ensures that the items are suitable for resale.
4. Non-Refundable Postage and Insurance Charges:
Postage and insurance charges associated with the return are non-refundable, whether it is for a refund or a new shipment. This policy is in place to cover the costs incurred during the initial shipping and to maintain fairness in the return process.
5. Non-Refundable Shipping Fees:
Shipping fees are non-refundable under any circumstances. This includes fees associated with the initial shipment of the product as well as any return or exchange shipments. This policy helps manage costs associated with logistics and ensures transparency in our transactions.
MV238FHB-N62 LCD Panel FAQ :
Q: If I place order now,when will you ship the goods of MV238FHB-N62?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can I pay my order of MV238FHB-N62via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can You declare my order of MV238FHB-N62 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long will I receive my goods MV238FHB-N62?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
