LCD Laptop Screen

New 15.6 inch TM156CFSP01-00 4K LCD Display Panel

All Category

Floor Standing Digital Signage

Multi Touch Screen Panel

chance

info@yongs-hk.com

86-18575563918

Contact Now

New 15.6 inch TM156CFSP01-00 4K LCD Display Panel

Brand Name:	TIANMA
Model Number:	TM156CFSP01-00
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

TM156CFSP01-00

Diagonal Size:

15.6"

Panel Type:

A-Si TFT-LCD, CELL, FOB

Resolution:

3840(RGB)×2160, UHD 282PPI

Application:

Laptop

Lamp Type:

No B/L

Refresh Rate:

Color Depth:

16.7M 72% NTSC

Plate Thickness:

0.15+0.15 Mm

Work Mode:

SFT, Normally Black, Transmissive

Supply Ability:

100000 Unit/Units per Month

Product Description

New 15.6 inch TM156CFSP01-00 4K LCD Display Panel

TM156CFSP01-00 LCD Panel Product details :

Brand	TIANMA
Model P/N	TM156CFSP01-00
Diagonal Size	15.6"
Panel Type	a-Si TFT-LCD, CELL, FOB
Resolution	3840(RGB)×2160, UHD 282PPI
Pixel Format	RGB Vertical Stripe
Active Area	345.6(W)×194.4(H) mm
Bezel Opening	-
Outline Dim.	349.94(H)×203.97(V) ×0.85(D) mm
Treatment	Hard coating
Luminance	0 cd/m²
Contrast Ratio	1200:1 (Typ.) (TM)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Response	14/15 (Typ.)(Tr/Td)
Good View at	Symmetry
Work Mode	SFT, Normally Black, Transmissive
Plate Thickness	0.15+0.15 mm
Transmittance	4.7% (Typ.)(with APCF)
Color Depth	16.7M 72% NTSC
Backlight	No B/L
Form Style	-
Used for	Laptop
Refresh Rate	60Hz
Touchscreen	Without
Driver IC list	COG Built-in TC2058BG4BLK-A0*8
Signal Type	eDP (4 Lanes) , 40 pins Connector
Power Supply	3.3V (Typ.)
Max. Ratings	Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

TM156CFSP01-00 LCD Panel Shipping and Package :

TM156CFSP01-00 LCD Screen Packing:

Rest assured, your parcel will be meticulously prepared to ensure its safe transit. Each item will be securely enclosed within a protective bubble bag before being placed in a robust and durable box. We take great care in packaging our products to withstand the rigors of transportation, providing you with peace of mind throughout the delivery process. Should you have any concerns or special requests regarding the packaging, please do not hesitate to reach out to our team.

TM156CFSP01-00 LCD Screen Reminder :

Product Accuracy: While product information may be sourced from the internet, rest assured that the images provided are genuine representations of the item you will receive. We take great care to ensure that your order is shipped exactly as depicted in our pictures. To avoid any inconvenience, we kindly request that you compare our images with your desired product prior to purchase. Please note that return postal costs resulting from an incorrect purchase are the responsibility of the buyer.

Order Processing Time: Your order will be processed and shipped within 2-7 working days from the date of purchase. We endeavor to expedite this process to ensure prompt delivery of your item.

Estimated Arrival Time: The estimated arrival time for your order is between 30-60 days, or potentially longer depending on the efficiency of the postal service in your country. We appreciate your patience and understanding regarding any delays that may occur during transit. If you have not received your product within the specified time frame, we kindly ask for your patience and suggest waiting a few additional days for delivery.

TM156CFSP01-00 LCD Screen Attention of receiving :

Upon receiving the products from the express company, it is imperative to conduct a thorough inspection of the package in person. Carefully examine the package for any signs of damage or tampering. Should you notice any discrepancies such as a broken package or damaged product, kindly decline acceptance of the delivery and promptly notify the courier. We strongly advise capturing photographic evidence of the damaged package or product from multiple angles.

The photographic evidence should be divided into two parts. The first set of photos serves as evidence for your own records, while the second set should be forwarded to the express company as a third-party verification. This dual approach ensures comprehensive documentation of the incident.

Upon receipt of the photographic evidence from the express company, detailing the condition of the damaged product, we will initiate an investigation to determine liability for the damages incurred. It is important to note that without corroborating evidence from the third party, we may be unable to proceed with compensation for the damaged product.

In instances where the product is not defective and a return is initiated, the buyer assumes responsibility for covering the return shipping costs and insurance. Additionally, a restocking fee of 25% will be applied to returned items that are not defective.

TM156CFSP01-00 LCD Panel FAQ :

Q: If I place order now,when will you ship the goods TM156CFSP01-00 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can you give me a discount if I need a large quantity TM156CFSP01-00 ?

A: Of course!If you make a large order, we will give you a discount.

Q: How long will I receive my goods TM156CFSP01-00 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

Q: How to make payment TM156CFSP01-00 ?

A: We accept T/T , Paypal , western union .
