TVL-55682D101U-LW-I-AAN LCD 10.1 inch 1024*600 TFT-LCD Screen Display
Product Details:
| Place of Origin: | China |
| Brand Name: | Kyocera |
| Model Number: | TVL-55682D101U-LW-I-AAN |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TVL-55682D101U-LW-I-AAN | Diagonal Size: | 10.1" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 1024(RGB)×600, WSVGA 117PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 222.72(W)×125.28(H) Mm |
| Brightness: | 200 Cd/m² (Typ.) | Contrast Ratio: | 500:1 (Typ.) (TM) |
| Application: | Industrial | Input Voltage: | 3.3V (Typ.) |
Product Description
TVL-55682D101U-LW-I-AAN LCD 10.1 inch 1024*600 TFT-LCD Screen Display
TVL-55682D101U-LW-I-AAN LCD Panel Product details :
| Brand | Kyocera |
| Model P/N | TVL-55682D101U-LW-I-AAN |
| Diagonal Size | 10.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×600, WSVGA 117PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 222.72(W)×125.28(H) mm |
| Bezel Opening | - |
| Outline Size | 235.5(W)×143.5(H)×5.2(D) mm |
| Surface | Antiglare |
| Brightness | 200 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 45/45/15/35 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 3/5 (Typ.)(Tr/Td) |
| Display Colors | 262K 45%NTSC |
| Lamp Type | WLED, 10K hours, With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 190g (Max.) |
| Application | Industrial |
| Signal Interface | LVDS (1 ch, 6-bit), 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C |
| TVL-55682D101U-LW-I-AAN LCD 10.1 inch 1024*600 TFT-LCD Screen Display | |
