LD430EQE-FQA1 51 pins 43.0 inch LCD Display For Digital Signage
Product Details:
| Place of Origin: | China |
| Brand Name: | LG |
| Model Number: | LD430EQE-FQA1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LD430EQE-FQA1 | Diagonal Size: | 43" |
|---|---|---|---|
| Panel Type: | A-Si TFT-LCD, LCM | Resolution: | 3840(RGB)×2160, UHD 103PPI |
| Pixel Format: | RGB Vertical Stripe | Active Area: | 941.184(W)×529.416(H) Mm |
| Display Colors: | 1.07B 98%sRGB | Designed For: | Digital Signage |
Product Description
LD430EQE-FQA1 51 pins 43.0 inch LCD Display For Digital Signage
LD430EQE-FQA1 LCD Panel Product details :
| Brand | LG Display |
| Model P/N | LD430EQE-FQA1 |
| Diagonal Size | 43" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 3840(RGB)×2160, UHD 103PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 941.184(W)×529.416(H) mm |
| Bezel Opening | - |
| Outline(mm) | 962 × 554.8× 34.6 (H×V×D) |
| Treatment | Antiglare (Haze 28%), Hard coating (2H) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) |
| Response | 6 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Color Depth | 1.07B 98%sRGB |
| Backlight | 3 strings × 2CNWLED, 30K hours, No Driver |
| Mass | 8.3/8.7Kgs (Typ./Max.) |
| Used for | Digital Signage |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | V-by-One 8 lane, 51 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LD430EQE-FQA1 51 pins 43.0 inch LCD Display For Digital Signage | |
